FRONT DRIVE GEARCASE ASSEMBLY для Arctic Cat THUNDERCAT (SILVER) [A2009IEW4EUSL] - 2009 года выпуска

  • №
    Артикул
    Название
  • 1502-395 GEARCASE, FRONT DRIVE COMPLETE ASSEMBLY
    GEARCASE, FRONT DRIVE COMPLETE ASSEMBLY
  • 1
    0502-923 SHAFT, PROPELLER - ASSEMBLY (INC. 2-3)
    SHAFT, PROPELLER - ASSEMBLY (INC. 2-3)
  • 2
    1402-438 ...SHAFT, INPUT
    ...SHAFT, INPUT
  • 3
    1402-168 ...DEFLECTOR
    ...DEFLECTOR
  • 4
    1402-011 SEAL
    SEAL
  • 5
    0423-423 RING, RETAINING
    RING, RETAINING
  • 6
    1502-237 BRACKET, ACTUATOR
    BRACKET, ACTUATOR
  • 7
    0502-585 ACTUATOR
    ACTUATOR
  • 8
    0423-892 O-RING
    O-RING
  • 9
    0423-396 SCREW, SELF TAP-TSPH M6-1.0X15
    SCREW, SELF TAP-TSPH M6-1.0X15
  • 10
    1402-043 BEARING, BALL - DOUBLE ROW
    BEARING, BALL - DOUBLE ROW
  • 11
    0423-118 SCREW, SELF TAP-TSPNH M8X1.25X40
    SCREW, SELF TAP-TSPNH M8X1.25X40
  • 12
    0502-528 HOUSING, PINION
    HOUSING, PINION
  • 13
    0402-947 GASKET
    GASKET
  • 14
    0423-417 RING, RETAINING
    RING, RETAINING
  • 15
    0402-413 COUPLER, DRIVE
    COUPLER, DRIVE
  • 16
    0402-357 COLLAR, LOCK
    COLLAR, LOCK
  • 17
    0502-784 GEAR, PINION - ASSEMBLY - 11T (INC. 18-19)
    GEAR, PINION - ASSEMBLY - 11T (INC. 18-19)
  • 18
    0402-336 ...COLLAR, RETAINING
    ...COLLAR, RETAINING
  • 19
    0402-327 ...BEARING
    ...BEARING
  • 20
    0402-328 BEARING
    BEARING
  • 21
    0502-514 HOUSING, GEARCASE
    HOUSING, GEARCASE
  • 22
    0402-411 PIN, DOWEL
    PIN, DOWEL
  • 23
    0402-999 SPRING, RETURN
    SPRING, RETURN
  • 24
    0423-147 O-RING
    O-RING
  • 25
    0402-417 SHAFT, SHUTTLE
    SHAFT, SHUTTLE
  • 26
    0402-998 FORK, SELECTOR
    FORK, SELECTOR
  • 27
    0423-402 RING, RETAINING
    RING, RETAINING
  • 28
    0402-997 SHAFT, SELECTOR
    SHAFT, SELECTOR
  • 29
    1402-210 PLUG, MAGNETIC (INC. ONE NO. 30)
    PLUG, MAGNETIC (INC. ONE NO. 30)
  • 30
    0423-153 ...O-RING
    ...O-RING
  • 31
    0423-149 O-RING
    O-RING
  • 32
    0402-393 BEARING
    BEARING
  • 33
    0402-405 SHIM, 41X49X1.3
    SHIM, 41X49X1.3
  • 33
    0402-406 SHIM, 41X49X1.4
    SHIM, 41X49X1.4
  • 33
    0402-407 SHIM, 41X49X1.5
    SHIM, 41X49X1.5
  • 33
    0402-408 SHIM, 41X49X1.6
    SHIM, 41X49X1.6
  • 33
    0402-409 SHIM, 41X49X1.7
    SHIM, 41X49X1.7
  • 34
    1502-506 GEAR, RING - 34T
    GEAR, RING - 34T
  • 35
    1402-074 SHIM, 1.3
    SHIM, 1.3
  • 35
    1402-075 SHIM, 1.4
    SHIM, 1.4
  • 35
    1402-076 SHIM, 1.5
    SHIM, 1.5
  • 35
    1402-077 SHIM, 1.6
    SHIM, 1.6
  • 35
    1402-078 SHIM, 1.7
    SHIM, 1.7
  • 36
    1502-389 COVER, GEARCASE (INC. ONE NO. 30 AND 37-49)
    COVER, GEARCASE (INC. ONE NO. 30 AND 37-49)
  • 37
    1402-053 ...BEARING
    ...BEARING
  • 38
    0502-413 ...FLANGE, BEARING
    ...FLANGE, BEARING
  • 39
    1402-079 ...PIN, ALIGNMENT
    ...PIN, ALIGNMENT
  • 40
    1402-042 ...COLLAR, SLIDING
    ...COLLAR, SLIDING
  • 41
    1402-054 ...FORK
    ...FORK
  • 42
    1402-058 ...RING, RETAINING
    ...RING, RETAINING
  • 43
    1402-057 ...SPRING
    ...SPRING
  • 44
    1402-063 ...SPRING
    ...SPRING
  • 45
    1402-656 ...SHAFT, LOCK
    ...SHAFT, LOCK
  • 46
    1402-104 ...FITTING
    ...FITTING
  • 47
    1402-056 ...SEAL
    ...SEAL
  • 48
    1402-713 ...SEAL
    ...SEAL
  • 49
    1402-211 ...PLUG, OIL LEVEL (INC. ONE NO. 30)
    ...PLUG, OIL LEVEL (INC. ONE NO. 30)
  • 50
    0402-333 PLUG, FILL (INC. 51)
    PLUG, FILL (INC. 51)
  • 51
    0423-154 ...O-RING
    ...O-RING
