DASH ASSEMBLY для Arctic Cat PROWLER (GREEN) [U2008P1S4BUSG] - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    2406-505 KIT-PANEL,DASH-PROWLER(STANDARD/XT)
    KIT-PANEL,DASH-PROWLER(STANDARD/XT)
  • 2
    1406-727 POD, INSTRUMENT
    POD, INSTRUMENT
  • 3
    0405-214 BEZEL, LIGHTS - INSTRUMENT POD
    BEZEL, LIGHTS - INSTRUMENT POD
  • 4
    0420-068 LIGHT, INDICATOR - TEMPERATURE
    LIGHT, INDICATOR - TEMPERATURE
  • 5
    0420-066 LIGHT, INDICATOR - "N"
    LIGHT, INDICATOR - "N"
  • 6
    0420-067 LIGHT, INDICATOR - "R"
    LIGHT, INDICATOR - "R"
  • 7
    0423-357 NUT, STAMPED
    NUT, STAMPED
  • 8
    0423-342 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 9
    0623-784 SCREW, SELF TAP-TSTRH #10-12X3/4 TP A BLK
    SCREW, SELF TAP-TSTRH #10-12X3/4 TP A BLK
  • 10
    0641-897 OUTLET, ACCESSORY - 12V
    OUTLET, ACCESSORY - 12V
  • 11
    0430-040 SWITCH, IGNITION (INC. 12-14)
    SWITCH, IGNITION (INC. 12-14)
  • 12
    0430-050 ...NUT, FLANGE - KEY SWITCH
    ...NUT, FLANGE - KEY SWITCH
  • 13
    0430-042 ...KEY, IGNITION-SERIES (Y) (LEFT SIDE KEY)
    ...KEY, IGNITION-SERIES (Y) (LEFT SIDE KEY)
  • 13
    0430-043 ...KEY, IGNITION-SERIES (Z) (RIGHT SIDE KEY)
    ...KEY, IGNITION-SERIES (Z) (RIGHT SIDE KEY)
  • 14
    0430-054 ...COVER, KEY
    ...COVER, KEY
  • 15
    0423-541 GROMMET, LATCH - GLOVE BOX
    GROMMET, LATCH - GLOVE BOX
  • 16
    1406-789 COVER, GLOVE BOX - BLACK
    COVER, GLOVE BOX - BLACK
  • 17
    0409-069 PANEL, SWITCH-MOUNT
    PANEL, SWITCH-MOUNT
  • 18
    0409-067 SWITCH - LIGHTS
    SWITCH - LIGHTS
  • 19
    0409-074 SWITCH, 2WD/4WD
    SWITCH, 2WD/4WD
  • 20
    0409-070 PLUG, SWITCH HOLE
    PLUG, SWITCH HOLE
  • 21
    0502-905 LEVER, DIFFERENTIAL LOCK - ASSEMBLY
    LEVER, DIFFERENTIAL LOCK - ASSEMBLY
  • 22
    2506-192 BRACKET, SUPPORT-LOWER-DASH-BLK
    BRACKET, SUPPORT-LOWER-DASH-BLK
  • 23
    0420-076 LIGHT, INDICATOR-PARKING BRAKE
    LIGHT, INDICATOR-PARKING BRAKE
