CANOPY AND TAILLIGHT ASSEMBLY для Arctic Cat PROWLER (GREEN) [U2008P1S4BUSG] - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    1506-680 CANOPY TUBE, REAR-PAINTED
    CANOPY TUBE, REAR-PAINTED
  • 2
    1506-713 CANOPY SUPPORT-PAINTED
    CANOPY SUPPORT-PAINTED
  • 3
    0423-361 SCREW, MACH-TSTRH M6-1.0 X 12 CL8.8 BLK
    SCREW, MACH-TSTRH M6-1.0 X 12 CL8.8 BLK
  • 4
    1506-665 CANOPY TUBE, FRONT-PAINTED
    CANOPY TUBE, FRONT-PAINTED
  • 5
    0423-817 SCREW, MACHINE
    SCREW, MACHINE
  • 6
    1506-795 PAD, HEADREST - ASSEMBLY (INC. 7-9)
    PAD, HEADREST - ASSEMBLY (INC. 7-9)
  • 7
    1406-884 ...PAD, HEADREST
    ...PAD, HEADREST
  • 8
    1506-722 ...HEADREST MOUNT-PAINTED-BLACK
    ...HEADREST MOUNT-PAINTED-BLACK
  • 9
    0623-544 ...PLUG
    ...PLUG
  • 10
    0423-419 SCREW, MACH-TSTRH-M6-1.0 X 16 BLACK
    SCREW, MACH-TSTRH-M6-1.0 X 16 BLACK
  • 11
    0423-577 CLIP, U-NUT
    CLIP, U-NUT
  • 12
    2406-069 BRACKET, TAILLIGHT MOUNT-BLACK
    BRACKET, TAILLIGHT MOUNT-BLACK
  • 13
    0623-301 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 14
    0509-022 TAILLIGHT ASSEMBLY (INC. 15-17)
    TAILLIGHT ASSEMBLY (INC. 15-17)
  • 15
    0509-025 ...HOUSING, TAILLIGHT
    ...HOUSING, TAILLIGHT
  • 16
    0409-056 ...BULB, TAIL LIGHT-3157
    ...BULB, TAIL LIGHT-3157
  • 17
    0409-057 ...SOCKET, TAILLIGHT
    ...SOCKET, TAILLIGHT
