HANDLEBAR PAD W/ STEERING GATE для Yamaha VK PROFESSIONAL II - 2018 года выпуска`
-
№АртикулНазвание
-
18LP-23870-00-00 STEERING GATE COMP.STEERING GATE COMP.
-
28V0-23858-00-00 SPACERSPACER
-
390105-081A7-00 BOLT, FLANGEBOLT, FLANGE
-
490201-08326-00 WASHER, PLATEWASHER, PLATE
-
595822-08020-00 BOLT, FLANGEBOLT, FLANGE
-
68FA-2389E-00-00 LATCHLATCH
-
795602-08200-00 NUT, U FLANGENUT, U FLANGE
-
890462-10022-00 CLAMPCLAMP
-
98KW-23815-00-00 PAD, STEERINGPAD, STEERING
-
1090464-18246-00 CLAMPCLAMP
-
1190464-09129-00 CLAMPCLAMP
-
1290464-17003-00 CLAMPCLAMP
-
138FA-2389C-E0-00 LABEL, CAUTIONLABEL, CAUTION
