AIR CLEANER W/ INTAKE для Yamaha MT07 - 2019 года выпуска`
-
№АртикулНазвание
-
11WS-13750-00-00 THROTTLE BODY ASSY (EXCEPT CALIF)THROTTLE BODY ASSY (EXCEPT CALIF)
-
11WS-13750-10-00 THROTTLE BODY ASSY (CALIF ONLY)THROTTLE BODY ASSY (CALIF ONLY)
-
28FP-13556-00-00 ...RUBBER, INJECTOR...RUBBER, INJECTOR
-
31WS-13761-00-00 ...INJECTOR...INJECTOR
-
45PS-14147-00-00 ......O-RING......O-RING
-
51WS-85801-00-00 ...STEPPING MOTOR...STEPPING MOTOR
-
654P-E416A-00-00 ......O-RING......O-RING
-
71WS-14335-00-00 ...SPRING, PLUNGER...SPRING, PLUNGER
-
898502-06012-00 ...SCREW, PAN HEAD...SCREW, PAN HEAD
-
954P-14243-00-00 ...PLATE...PLATE
-
101WS-13938-00-00 ...PIPE...PIPE
-
118HG-13573-00-00 ...BOLT 1...BOLT 1
-
128GL-13571-00-00 ...WASHER...WASHER
-
138HG-14534-00-00 ...COLLAR...COLLAR
-
148CC-14216-10-00 ...SCREW...SCREW
-
153B4-85885-00-00 ...THROTTLE SENSOR ASSY...THROTTLE SENSOR ASSY
-
162C0-14105-00-00 ...PILOT SCREW SET...PILOT SCREW SET
-
1790413-06031-00 ...WAY 3 (CALIF ONLY)...WAY 3 (CALIF ONLY)
-
1890467-090A2-00 ...CLIP (CALIF ONLY)...CLIP (CALIF ONLY)
-
191WS-14465-00-00 ...PIPE (CALIF ONLY)...PIPE (CALIF ONLY)
-
2014B-14466-00-00 ...PIPE (CALIF ONLY)...PIPE (CALIF ONLY)
-
21895-14169-00-00 CAPCAP
-
228A7-14139-00-00 CLIP, PIPECLIP, PIPE
