AIR CLEANER W/ INTAKE для Yamaha FZ6R - 2010 года выпуска`
-
№АртикулНазвание
-
120S-13750-00-00 THROTTLE BODY ASSY (EXCEPT CALIF)THROTTLE BODY ASSY (EXCEPT CALIF)
-
136P-13750-00-00 THROTTLE BODY ASSY (CALIF ONLY)THROTTLE BODY ASSY (CALIF ONLY)
-
25VX-14348-00-00 PIPE 1PIPE 1
-
38FP-13556-00-00 GASKET, MANIFOLDGASKET, MANIFOLD
-
45VX-13761-00-00 INJECTORINJECTOR
-
55PS-14147-00-00 O-RINGO-RING
-
62D1-85885-00-00 THROTTLE SENSOR ASSYTHROTTLE SENSOR ASSY
-
74KM-24453-00-00 SCREWSCREW
-
85VX-14149-00-00 PIPEPIPE
-
95VX-14565-00-00 SCREWSCREW
-
1098507-05010-00 SCREW, PAN HEAD (3SX)SCREW, PAN HEAD (3SX)
-
1198507-06012-00 SCREW, PAN HEADSCREW, PAN HEAD
-
125VX-14396-00-00 PIPEPIPE
-
133UH-14937-00-00 CLIPCLIP
-
145VX-14987-00-00 HOSEHOSE
-
1568V-24376-00-00 PIPE, JOINT 1PIPE, JOINT 1
-
163XV-14251-00-00 NIPPLENIPPLE
-
175FL-14348-10-00 PIPE 1PIPE 1
-
1868V-13533-00-00 HOSE, VACUUM SENSING 4HOSE, VACUUM SENSING 4
-
195VX-1410E-00-00 HOSEHOSE
-
205PW-14251-00-00 NIPPLENIPPLE
-
214KM-14137-00-00 CLIPCLIP
-
225JW-14104-00-00 AIR SCREW SETAIR SCREW SET
-
233H1-14147-00-00 O-RINGO-RING
-
245VX-14349-00-00 PIPEPIPE
-
2590467-11090-00 CLIP,SCISSORCLIP,SCISSOR
-
2620S-1243E-00-00 HOSE 2HOSE 2
-
275VX-13160-00-00 DELIVERY PIPE ASSY 1DELIVERY PIPE ASSY 1
-
2820S-82386-00-00 EXTENSION, WIRE HARNESSEXTENSION, WIRE HARNESS
-
295VX-13533-00-00 HOSE, VACUUM SENSING 4HOSE, VACUUM SENSING 4
-
305VX-14807-00-00 HOSEHOSE
-
315VX-14503-00-00 ADJUST SCREW SETADJUST SCREW SET
-
3290464-23041-00 CLAMPCLAMP
-
335VX-14465-01-00 PIPE (CALIF ONLY)PIPE (CALIF ONLY)
-
3490467-10008-00 CLIP (CALIF ONLY)CLIP (CALIF ONLY)
-
3590413-08012-00 3 WAY TEE (CALIF ONLY)3 WAY TEE (CALIF ONLY)
