AIR CLEANER W/ INTAKE для Yamaha FJR1300AE ABS - 2009 года выпуска`
-
№АртикулНазвание
-
13P6-13750-20-00 THROTTLE BODY ASSY (EXCEPT CALIF.)THROTTLE BODY ASSY (EXCEPT CALIF.)
-
13P6-13750-30-00 THROTTLE BODY ASSY (CALIF. ONLY)THROTTLE BODY ASSY (CALIF. ONLY)
-
290430-09002-00 GASKETGASKET
-
35JW-13761-10-00 INJECTORINJECTOR
-
45FL-14147-00-00 O-RINGO-RING
-
598502-05012-00 SCREW, PAN HEADSCREW, PAN HEAD
-
65JW-14419-00-00 PIPEPIPE
-
798502-06040-00 SCREW, PAN HEADSCREW, PAN HEAD
-
85JW-13160-00-00 DELIVERY PIPE SETDELIVERY PIPE SET
-
95JW-14589-00-00 SPRINGSPRING
-
105JW-14349-20-00 PIPEPIPE
-
115JW-14349-10-00 PIPEPIPE
-
125PW-14349-00-00 PIPEPIPE
-
133XV-14251-00-00 NIPPLENIPPLE
-
145JW-14987-10-00 HOSEHOSE
-
155JW-14987-20-00 HOSEHOSE
-
165DM-14919-00-00 CLIPCLIP
-
175JW-82380-00-00 SENSOR, PRESSURESENSOR, PRESSURE
-
183P6-85885-00-00 THROTTLE SENSOR ASSYTHROTTLE SENSOR ASSY
-
198CC-14216-10-00 SCREWSCREW
-
205JW-82509-10-00 WIRE, SUB LEADWIRE, SUB LEAD
-
215JW-14104-00-00 AIR SCREW SETAIR SCREW SET
-
224KM-14137-00-00 CLIPCLIP
-
2398502-05006-00 SCREW, PAN HEADSCREW, PAN HEAD
-
243P6-14139-00-00 CLIP, PIPECLIP, PIPE
-
25895-14169-00-00 CAPCAP
-
268A7-14139-00-00 CLIP, PIPECLIP, PIPE
-
275PW-14137-00-00 CLIPCLIP
-
285JW-14103-20-00 THROTTLE SCREW SETTHROTTLE SCREW SET
-
295JW-14987-30-00 HOSEHOSE
-
3097002-05016-00 BOLTBOLT
-
3192902-05600-00 WASHER, PLATEWASHER, PLATE
-
325JW-14413-10-00 STAYSTAY
-
335JW-13971-10-00 PIPE, FUEL 1PIPE, FUEL 1
-
3490464-16005-00 CLAMPCLAMP
