HANDLEBAR ASSEMBLY W/ CONTROLS для Polaris 800 IQ (S08PB8ES) - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    5434715-070 GRIP-HANDLEBAR, STD, BLACK
    GRIP-HANDLEBAR, STD, BLACK
  • 2
    7555730 WASHER
    WASHER
  • 3
    7661624 PIN-RETAINING
    PIN-RETAINING
  • 4
    7710503 RING, RETAINING
    RING, RETAINING
  • 5
    5432970 THROTTLE, LEVER, 35.5MM
    THROTTLE, LEVER, 35.5MM
  • 6
    4011540 SWITCH-AUX SHUT-OFF
    SWITCH-AUX SHUT-OFF
  • 7
    5430604 BLOCK-ADAPTER
    BLOCK-ADAPTER
  • 8
    5252170-0678 BOLT
    BOLT
  • 10
    7558402 WASHER, FLAT
    WASHER, FLAT
  • 11
    2683859 ASM-HANDLEBAR COVER, RACE
    ASM-HANDLEBAR COVER, RACE
  • 12
    5631311 CLAMP-HANDLE BAR, RETAINER
    CLAMP-HANDLE BAR, RETAINER
  • 13
    2410777 HEATER-GRIP, LO/MED/HI, SHORT
    HEATER-GRIP, LO/MED/HI, SHORT
  • 14
    5431592 BLOCK, THROTTLE/BRAKE
    BLOCK, THROTTLE/BRAKE
  • 15
    7710401 RING, RETAINING
    RING, RETAINING
  • 16
    5433291 BUTTON SWITCH HI/LO, LEFT HAND CONTROL
    BUTTON SWITCH HI/LO, LEFT HAND CONTROL
  • 17
    2010237 ASM-CONTROL, LEFT HAND, MFG (INCL. 16)
    ASM-CONTROL, LEFT HAND, MFG (INCL. 16)
  • 18
    7517566 SCREW, 1.50
    SCREW, 1.50
  • 19
    7512078 SCREW, 1.12
    SCREW, 1.12
  • 20
    7517441 SCREW, .75
    SCREW, .75
  • 21
    5135881 BLOCK-HB RISER, 3.75'' OFFSET
    BLOCK-HB RISER, 3.75'' OFFSET
  • 22
    7081332 CABLE-THROTTLE, SDI
    CABLE-THROTTLE, SDI
  • 23
    7511848 SCREW
    SCREW
  • 24
    7555727 WASHER
    WASHER
  • 25
    7512465 SCREW, SET
    SCREW, SET
