SUSPENSION - RAIL MOUNTING для Polaris 600 CLEANFIRE SWITCHBACK AND STOCK A/B (S07PS6HS/HAS/HSB) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    7518335 BOLT-10-24X1
    BOLT-10-24X1
  • 2
    7555792 WASHER
    WASHER
  • 3
    7510504 SCREW
    SCREW
  • 4
    7555783 WASHER, FLAT
    WASHER, FLAT
  • 5
    5521498 BUMPER, JOUNCE REAR
    BUMPER, JOUNCE REAR
  • 5
    5432946 LINER, BUMPER
    LINER, BUMPER
  • 6
    7541925 NUT, NYLOK 10-24 Y
    NUT, NYLOK 10-24 Y
  • 7
    1542033 ASM-RAIL, BSC, 144, LWT, LEFT HAND [INCL. 1-7, 16, 17, 25, 26]
    ASM-RAIL, BSC, 144, LWT, LEFT HAND [INCL. 1-7, 16, 17, 25, 26]
  • 7
    1542034 ASM-RAIL, BSC, 144, LWT, RIGHT HAND [INCL. 1-7, 16, 17, 25, 26]
    ASM-RAIL, BSC, 144, LWT, RIGHT HAND [INCL. 1-7, 16, 17, 25, 26]
  • 8
    7547263 NUT-3/8-24 NYLOK
    NUT-3/8-24 NYLOK
  • 9
    7555983 WASHER,FLAT
    WASHER,FLAT
  • 10
    7515317 BOLT
    BOLT
  • 11
    7542324 NUT, NYLOK
    NUT, NYLOK
  • 12
    5631446 BLOCK-WHEEL MOUNT, 6004
    BLOCK-WHEEL MOUNT, 6004
  • 13
    1590419-070 ASM-WHEEL, 5.62, 6004, BLACK
    ASM-WHEEL, 5.62, 6004, BLACK
  • 13
    7710444 RING, RETAINING [1 PER WHEEL]
    RING, RETAINING [1 PER WHEEL]
  • 13
    3514384 BEARING-.7874X1.6535X.4724, NTN [1 PER WHEEL]
    BEARING-.7874X1.6535X.4724, NTN [1 PER WHEEL]
  • 14
    7556179 WASHER-SPRING, CON 5/16X.090-Y
    WASHER-SPRING, CON 5/16X.090-Y
  • 15
    7515346 SCREW
    SCREW
  • 16
    7621501 RIVET
    RIVET
  • 17
    5130530 BLOCK-IDLER BOLT ADJ.
    BLOCK-IDLER BOLT ADJ.
  • 18
    7517227 SCREW
    SCREW
  • 19
    7542404 NUT
    NUT
  • 20
    7515415 SCREW
    SCREW
  • 21
    5434334 GUIDE-SPRING SQUARE
    GUIDE-SPRING SQUARE
  • 22
    5333948 SPACER-.407X.625X1.33
    SPACER-.407X.625X1.33
  • 23
    5521633 SLIDER, .45/74'', SERVICE, BASIC
    SLIDER, .45/74'', SERVICE, BASIC
  • 24
    7515199 SCREW
    SCREW
  • 25
    7541925 NUT, NYLOK 10-24 Y
    NUT, NYLOK 10-24 Y
  • 26
    5435527 CAP-RAIL TIP, UHMW
    CAP-RAIL TIP, UHMW
