SUSPENSION - FRONT SHOCK (FOX M-10) для Polaris 600 HO Fusion (S06MP6FS) - 2006 года выпуска`
-
№АртикулНазвание
-
11500710 REBUILD KITREBUILD KIT
-
21500734 PISTON-.093 BLEEDPISTON-.093 BLEED
-
31500016 NUT, LOCKNUT, LOCK
-
41500601 IFP ASSY.IFP ASSY.
-
51500161 SCREW W/O-RING ASSY.SCREW W/O-RING ASSY.
-
61500444 BEARING-RBCBEARING-RBC
-
71500014 VALVE ASSY., AIRVALVE ASSY., AIR
-
81500019 SCREWSCREW
-
91500006 RING, PISTON, FLOATINGRING, PISTON, FLOATING
-
101500002 DAMPER, PISTON RINGDAMPER, PISTON RING
-
111500485 SCRAPER-FIST, BRONZESCRAPER-FIST, BRONZE
-
121500310 SLEEVESLEEVE
-
131500164 EYELET, BASEEYELET, BASE
-
141500735 BUMPER B/OBUMPER B/O
-
151500309 BUSHINGBUSHING
-
161500736 SHAFTSHAFT
-
171500545 CYLINDER-HEAD O-RINGCYLINDER-HEAD O-RING
-
171700051 CYLINDER-HEAD O-RINGCYLINDER-HEAD O-RING
-
181500706 BODY, ALUM.BODY, ALUM.
-
191500707 RING, SPRING PRELOADRING, SPRING PRELOAD
-
201500708 RING, SPRING PRELOADRING, SPRING PRELOAD
-
211500709 BODY CAP ASSY.BODY CAP ASSY.
