STEERING POST ASSEMBLY для Polaris 800 RMK 159 VERTICAL ESCAPE (S03NN8CS) - 2003 года выпуска

  • №
    Артикул
    Название
  • 1
    5133648 BRACKET STEERING POST, MOD
    BRACKET STEERING POST, MOD
  • 1
    7080510 FITTING, ZERK, 90DEG
    FITTING, ZERK, 90DEG
  • 2
    5432785 BUSHING
    BUSHING
  • 3
    1821251-067 WELD, STEERING POST, EDGERMK, BLK
    WELD, STEERING POST, EDGERMK, BLK
  • 4
    7517579 BOLT CARR 5/16-X1"GR5 Y LO
    BOLT CARR 5/16-X1"GR5 Y LO
  • 5
    1013444-067 WELD STEERING HOOP (BLACK)
    WELD STEERING HOOP (BLACK)
  • 6
    7547030 PALNUT
    PALNUT
  • 7
    7512377 BOLT, CARRIAGE
    BOLT, CARRIAGE
  • 8
    7542343 NUT FLANGE
    NUT FLANGE
  • 9
    4020139 CLIP (ROSEBUD)
    CLIP (ROSEBUD)
  • 10
    7621433 RIVET
    RIVET
  • 11
    5244470 PLATE, TIE ROD BOOT
    PLATE, TIE ROD BOOT
  • 12
    5433532 BOOT, TIE ROD (LEFT)
    BOOT, TIE ROD (LEFT)
  • 12
    5433533 BOOT, TIE ROD (RIGHT)
    BOOT, TIE ROD (RIGHT)
  • 13
    7558402 WASHER, FLAT
    WASHER, FLAT
  • 14
    7542324 NUT NYLOK
    NUT NYLOK
  • 15
    5245373 BRACKET CONSOLE (FRONT) NECK, FWD, SRP
    BRACKET CONSOLE (FRONT) NECK, FWD, SRP
