CYLINDER W/ INTAKE для Polaris SLX 2-Pass Euro - 2000 года выпуска`
-
№АртикулНазвание
-
17516806 BOLTBOLT
-
27075383 DECAL, WARNINGDECAL, WARNING
-
35630942-093 WATER MANIFOLD ASSY.WATER MANIFOLD ASSY.
-
45830061 GASKET, WATER MANIFOLDGASKET, WATER MANIFOLD
-
53070163 SPARKPLUG (BR9ES)SPARKPLUG (BR9ES)
-
65630527-093 COVER, HEAD (RED)COVER, HEAD (RED)
-
75410917 O-RINGO-RING
-
85241944 RING, HEAD (81MM)RING, HEAD (81MM)
-
93021122 HEAD, CYLINDER (84MM)HEAD, CYLINDER (84MM)
-
102201562 CRANKCASE ASSY.CRANKCASE ASSY.
-
111201595 REED BLOCK ASSY.REED BLOCK ASSY.
-
125432162 STUFFER REED BLOCKSTUFFER REED BLOCK
-
135630582 ADAPTOR CARB (BLACK)ADAPTOR CARB (BLACK)
-
147516807 BOLTBOLT
-
157516814 BOLTBOLT
-
167080654 RETAINERRETAINER
-
175830043 GASKET, CARBURETORGASKET, CARBURETOR
-
185830123 GASKET, CYLINDER BASEGASKET, CYLINDER BASE
-
193021017 CYLINDER (84MM)CYLINDER (84MM)
-
207547021 NUTNUT
-
215410931 O-RINGO-RING
-
225411573 O-RINGO-RING
-
237517352 SCREWSCREW
-
247516722 BOLTBOLT
