MAGNETO для Polaris SLX 2-Pass Euro - 2000 года выпуска
-
№АртикулНазвание
-
14010170 STATOR ASSY.STATOR ASSY.
-
27517714 SCREWSCREW
-
37516822 SCREWSCREW
-
45243231 CLAMP, STATOR WIRESCLAMP, STATOR WIRES
-
55411320 O-RINGO-RING
-
65432282 HOLDER, MAGNETHOLDER, MAGNET
-
74010189 FLYWHEEL ASSY. (INCL. 5,6,8)FLYWHEEL ASSY. (INCL. 5,6,8)
-
82201228 TIMING SCREWS KITTIMING SCREWS KIT
-
97555907 WASHERWASHER
-
107546909 NUTNUT
-
112460717 HARNESS-9, WIRE STATORHARNESS-9, WIRE STATOR
-
124010379 CONTROLLER, IGNITIONCONTROLLER, IGNITION
-
134010174 COIL, IGNITIONCOIL, IGNITION
-
144010228 SOLENOID, STARTERSOLENOID, STARTER
-
154010173-71 SPARK PLUG WIRESPARK PLUG WIRE
-
167080138 CABLE TIECABLE TIE
-
177080483 CABLE TIE (4 INCH)CABLE TIE (4 INCH)
-
184010173-56 SPARK PLUG WIRESPARK PLUG WIRE
-
194010173-42 SPARK PLUG WIRESPARK PLUG WIRE
