INTAKE GRATE W/ RIDE PLATE для Polaris SLX 2-Pass Euro - 2000 года выпуска`
-
№АртикулНазвание
-
18450070-235 PITOT LINE, 90 DEGREE FORMEDPITOT LINE, 90 DEGREE FORMED
-
27080483 CABLE TIE (4 INCH)CABLE TIE (4 INCH)
-
37547003 NUTNUT
-
47555873 WASHER, FLAT NYLONWASHER, FLAT NYLON
-
55810879 GASKET, PITOTGASKET, PITOT
-
65431634 FITTING, PILOT MOLDEDFITTING, PILOT MOLDED
-
75131602 SCOOP, INLETSCOOP, INLET
-
85410652 O-RING, BPUMP HOUSING/HULLO-RING, BPUMP HOUSING/HULL
-
97010083 INSERT, SPONSON / RIDEPLATEINSERT, SPONSON / RIDEPLATE
-
105630737 PLATE, RIDE EXT.PLATE, RIDE EXT.
-
117515126 BOLTBOLT
-
127517267 SCREWSCREW
-
137515155 BOLTBOLT
-
145630542-067 GRATE, INLET (BLACK)GRATE, INLET (BLACK)
Все узлы модели:
- AIR INTAKE SYSTEM
- BATTERY BOX
- BILGE PUMP
- CARBURETOR
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTONS
- CYLINDER W/ INTAKE
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ENGINE FOGGING SYSTEM
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FUEL / WATER SEPARATOR
- FUEL SYSTEM
- FUEL TANK
- HANDLEBAR ASSY. W/ STEERING COLUMN
- HULL
- HULL
- • INTAKE GRATE W/ RIDE PLATE
- MAGNETO
- OIL PUMP
- OIL TANK
- PROPULSION
- SEAT
- STARTING MOTOR
- STEERING CABLE ASSY.
- STORAGE COMPARTMENT - FRONT
- TOOL KIT
- TRIM ASSY.
