ENGINE MOUNTING W/ SHORT BLOCK для Polaris SLX 2-Pass Euro - 2000 года выпуска

  • №
    Артикул
    Название
  • 1
    2410188 SWITCH, TEMPERATURE 160 W/GROMMET
    SWITCH, TEMPERATURE 160 W/GROMMET
  • 2
    7077026 DECAL, SPARKPLUG REC.
    DECAL, SPARKPLUG REC.
  • 3
    5242476 GROUND, SPARKPLUG
    GROUND, SPARKPLUG
  • 4
    7515149 SCREW, SHOULDER
    SCREW, SHOULDER
  • 5
    5830051 GASKET, EXHAUST PIPE
    GASKET, EXHAUST PIPE
  • 6
    7075383 DECAL, WARNING
    DECAL, WARNING
  • 7
    5630585 PLATE, W/WASHER KIT (FRONT)
    PLATE, W/WASHER KIT (FRONT)
  • 8
    7552609 WASHER, LOCK
    WASHER, LOCK
  • 9
    7517330 SCREW
    SCREW
  • 10
    5630584 PLATE, W/WASHER KIT (REAR)
    PLATE, W/WASHER KIT (REAR)
  • 11
    3021103 MOUNT, ENGINE
    MOUNT, ENGINE
  • 12
    5211727 SHIM, ENGINE MOUNT
    SHIM, ENGINE MOUNT
  • 13
    7552610 WASHER, LOCK
    WASHER, LOCK
  • 14
    7517627 SCREW
    SCREW
  • 15
    7555848 WASHER, FLAT
    WASHER, FLAT
  • 16
    7542725 NUT, NYLOK
    NUT, NYLOK
  • 17
    7556055 WASHER, LOCK
    WASHER, LOCK
  • 18
    7517497 BOLT
    BOLT
  • 19
    2201704 SHORT BLOCK ASSY. (FOOTNOTE)
    SHORT BLOCK ASSY. (FOOTNOTE)
  • 20
    5240876 CLIP, RETAINER TEMPERATURE SWITCH
    CLIP, RETAINER TEMPERATURE SWITCH
  • 21
    7516603 BOLT
    BOLT
