ELECTRICAL COMPONENTS для Polaris PHOENIX 200 [A12PB20AF] - 2012 года выпуска
-
№АртикулНазвание
-
10452917 BOLTBOLT
-
20450701 BOLTBOLT
-
30453375 RECTIFIER/REGULATORRECTIFIER/REGULATOR
-
40452764 BRACKET, ELECTRICALBRACKET, ELECTRICAL
-
50454244 ASM., CDI (INCL. 6)ASM., CDI (INCL. 6)
-
60453473 PAD, RUBBERPAD, RUBBER
-
80454245 ASM., POUCH, TOOLASM., POUCH, TOOL
-
90450721 STRAPSTRAP
-
100454668 ASM., HARNESS, MAINASM., HARNESS, MAIN
-
110452744 FUSE, MAIN HARNESSFUSE, MAIN HARNESS
-
120450150 NUT, FLANGENUT, FLANGE
-
130452761 ASM., STARTER RELAYASM., STARTER RELAY
-
140450559 STRAPSTRAP
-
154011434 BATTERYBATTERY
-
160452767 ASM., BATTERY CABLEASM., BATTERY CABLE
-
170454669 INDICATOR, NEUTRALINDICATOR, NEUTRAL
-
180454670 INDICATOR, REVERSEINDICATOR, REVERSE
-
190452763 BOLTBOLT
-
200453364 CAP, SPARK PLUGCAP, SPARK PLUG
-
210452309 ASM., IGNITION COILASM., IGNITION COIL
-
220453144 CABLE, ETC, CONNECTINGCABLE, ETC, CONNECTING
-
230450886 CLIP, MAIN SWITCHCLIP, MAIN SWITCH
-
240453415 ASM., SWITCH, MAIN (INCL. 23,25)ASM., SWITCH, MAIN (INCL. 23,25)
-
250454728 KEY, BLANK, LEFT HANDKEY, BLANK, LEFT HAND
-
250454729 KEY, BLANK, RIGHT HANDKEY, BLANK, RIGHT HAND
-
260452660 STRAP, BATTERY, RUBBERSTRAP, BATTERY, RUBBER
