SUSPENSION - SWING ARM W/ SHOCK MOUNTING для Polaris OUTLAW 450 S (A09GJ45AA) - 2009 года выпуска
-
№АртикулНазвание
-
17043479-293 SPRINGSPRING
-
25510606 SPACER-SPRINGSPACER-SPRING
-
37043093-293 SPRING-COMP, 400#/IN, INDY REDSPRING-COMP, 400#/IN, INDY RED
-
41500597 RETAINER-SPRINGRETAINER-SPRING
-
57043473 SHOCK-REARSHOCK-REAR
-
67547066 NUT-7/16-20, NYLOK, YNUT-7/16-20, NYLOK, Y
-
75334195 BUSHING-REDUCER, .500 TO .4375BUSHING-REDUCER, .500 TO .4375
-
85412290 O-RING, 0.600IDX.210O-RING, 0.600IDX.210
-
97518207 BOLT-7/16-20X2.25, HXHDCP, G5, YBOLT-7/16-20X2.25, HXHDCP, G5, Y
