STEERING - TIE RODS W/LOWER ASSEMBYL для Polaris OUTLAW 450 S (A09GJ45AA) - 2009 года выпуска`
-
№АртикулНазвание
-
-1823523 ASM-TIE ROD (INCL. 7-11)ASM-TIE ROD (INCL. 7-11)
-
17661203 PIN, COTTERPIN, COTTER
-
27547333 NUT-M10X1.25, FLG, NYLOC-OLIVE DNUT-M10X1.25, FLG, NYLOC-OLIVE D
-
37555806 WASHER, FLATWASHER, FLAT
-
47518564 BOLT-M8X1.25X20, CARR-OLIVE DBOLT-M8X1.25X20, CARR-OLIVE D
-
57061140 ROD-END, M10X1.25, RIGHT HANDROD-END, M10X1.25, RIGHT HAND
-
67547390 NUT-JAM, M10X1.25, RIGHT HANDNUT-JAM, M10X1.25, RIGHT HAND
-
77061150 ROD-END, M10X1.25, LEFT HANDROD-END, M10X1.25, LEFT HAND
-
87547389 NUT-JAM, M10X1.25, LEFT HANDNUT-JAM, M10X1.25, LEFT HAND
-
95136677 TIE RODTIE ROD
-
107661011 PIN, COTTERPIN, COTTER
-
117547332 NUT-M8X1.25, FLG, NYLOC-OLIVE DNUT-M8X1.25, FLG, NYLOC-OLIVE D
