COOLING SYSTEM для Polaris OUTLAW 450 S (A09GJ45AA) - 2009 года выпуска

  • №
    Артикул
    Название
  • 1
    2520719 ASM-FAN AND MOTOR
    ASM-FAN AND MOTOR
  • 2
    7080696 CLAMP, HOSE, 1.25, WORM DRIVE
    CLAMP, HOSE, 1.25, WORM DRIVE
  • 3
    5413184 HOSE-RADIATOR, INLET
    HOSE-RADIATOR, INLET
  • 4
    4011771 SENSOR-THERMAL, DUAL TEMP
    SENSOR-THERMAL, DUAL TEMP
  • 5
    5410584 BUSHING-MOUNT, LOWER RADIATOR
    BUSHING-MOUNT, LOWER RADIATOR
  • 6
    1240325 CAP-PRESSURE, 20 PSI
    CAP-PRESSURE, 20 PSI
  • 7
    1240302 RADIATOR
    RADIATOR
  • 8
    5436136 SCREEN-RADIATOR
    SCREEN-RADIATOR
  • 9
    7519066 SCR-HXFLTX-M6X1.0X15 8.8 ZOD
    SCR-HXFLTX-M6X1.0X15 8.8 ZOD
  • 10
    5250821-458 BRKT-RADIATOR MOUNT, LOWER, M BK
    BRKT-RADIATOR MOUNT, LOWER, M BK
  • 11
    7519068 SCR-HXFLTX-M5X.8X10 8.8ZOD TDF
    SCR-HXFLTX-M5X.8X10 8.8ZOD TDF
  • 12
    5333796 SPACER
    SPACER
  • 13
    5410437 GROMMET
    GROMMET
  • 14
    5249162 BRKT-SURGE TANK
    BRKT-SURGE TANK
  • 15
    5434856 TANK-SURGE
    TANK-SURGE
  • 16
    7052065 FITTING, 90 DEGREE
    FITTING, 90 DEGREE
  • 17
    5433774 CAP, PLUG9X (GRN), FLEX TEMP
    CAP, PLUG9X (GRN), FLEX TEMP
  • 18
    5810279 GASKET
    GASKET
  • 19
    5812988 FOAM-CAP, SURGE TANK
    FOAM-CAP, SURGE TANK
  • 20
    5430743 CAP, OVERFLOW
    CAP, OVERFLOW
  • 21
    8450003-1525 LINE, FUEL, 1/4 ID(1525 CM.)
    LINE, FUEL, 1/4 ID(1525 CM.)
  • 22
    5413182 HOSE-RADIATOR, OUTLET
    HOSE-RADIATOR, OUTLET
  • 23
    7517975 BOLT-M6 HEX HD
    BOLT-M6 HEX HD
  • 24
    7547197 CLIP-''U'', M6.0X1.0
    CLIP-''U'', M6.0X1.0
  • 27
    7518590 SCR-TORX HD, M4.2X19, 0600129
    SCR-TORX HD, M4.2X19, 0600129
  • 28
    7052414 THERMOSTAT-70°C, 525ATV
    THERMOSTAT-70°C, 525ATV
  • 29
    5413232 O-RING-32.0X2.0MM
    O-RING-32.0X2.0MM
  • 30
    1203449 ASM-THERMOSTAT, REMOTE, 525 ATV (INCL. 25-29)
    ASM-THERMOSTAT, REMOTE, 525 ATV (INCL. 25-29)
  • 31
    5413185 HOSE-BYPASS
    HOSE-BYPASS
  • 32
    5413183 HOSE-ENGINE OUTLET
    HOSE-ENGINE OUTLET
  • 33
    7518647 BOLT-M6X1.0X8, PH/TX, LX-OLIVE D
    BOLT-M6X1.0X8, PH/TX, LX-OLIVE D
