OIL TANK (BUILT AFTER 1/01/02) для Polaris SCRAMBLER 500 4X4 (A02BG50AA) (BLAZING RED) - 2002 года выпуска`
-
№АртикулНазвание
-
15434307 DIPSTICK-GEN IIIDIPSTICK-GEN III
-
21261175 TANK OIL,PLASTIC,03 STYLETANK OIL,PLASTIC,03 STYLE
-
35411873 HOSE,BRTHR,SLIT,63CM,3/8I.DHOSE,BRTHR,SLIT,63CM,3/8I.D
-
45410828 GROMMET,MTG,RESERVOIRGROMMET,MTG,RESERVOIR
-
55333204 BUSHING,MTG.BUSHING,MTG.
-
67080699 CLAMP,HOSECLAMP,HOSE
-
77052326 SCREEN-OIL FILTER,900SCREEN-OIL FILTER,900
-
85412227 HOSE-FORMED,SCRAMBLER,1/2''IDHOSE-FORMED,SCRAMBLER,1/2''ID
-
97081026 CLAMP-HOSE,SPRING .81CLAMP-HOSE,SPRING .81
-
105850135 WASHERWASHER
-
117051524 PLUG,MAG.12 M.PLUG,MAG.12 M.
