CHOKE PLATE AND THROTTLE LEVERS(S/N-C239553 AND UP) для Mercury - V-200 0C100861 THRU 0C291519

  • №
    Артикул
    Название
  • 1
    817495A1 COVER, SOUND ATTENUATOR
    COVER, SOUND ATTENUATOR
  • 2
    10-92051 SCREW, (10-16 x .75)
    SCREW, (10-16 x .75)
  • 3
    27-188891 GASKET, SOUND ATTENUATOR
    GASKET, SOUND ATTENUATOR
  • 4
    817495A1 PLATE, Sound Attenuator
    PLATE, Sound Attenuator
  • 5
    27-892211 GASKET, PLATE TO CARBURETOR
    GASKET, PLATE TO CARBURETOR
  • 6
    10-68000 SCREW, (.250-28 x 1.00), SOUND ATTENUATOR
    SCREW, (.250-28 x 1.00), SOUND ATTENUATOR
  • 7
    12-20583 WASHER, SOUND ATTENUATOR SCREW
    WASHER, SOUND ATTENUATOR SCREW
  • 8
    21-64871A2 CHECK VALVE
    CHECK VALVE
  • 9
    22-15026 CAP
    CAP
  • 10
    87604 LINK, Throttle
    LINK, Throttle
  • 11
    828277A1 LEVER ASSEMBLY, Throttle
    LEVER ASSEMBLY, Throttle
  • 12
    828277A1 LEVER, Throttle
    LEVER, Throttle
  • 13
    67748 ROLLER, LOWER THROTTLE LEVER
    ROLLER, LOWER THROTTLE LEVER
  • 14
    10-15124 SCREW, (#10-32 x .750), THROTTLE LEVERS TO THROTTLE LINK
    SCREW, (#10-32 x .750), THROTTLE LEVERS TO THROTTLE LINK
  • 15
    13-26996 LOCKWASHER, (#10) Stainless Steel, THROTTLE LEVERS SCREW
    LOCKWASHER, (#10) Stainless Steel, THROTTLE LEVERS SCREW
  • 16
    12-56681 WASHER, (.203 x .500 x .032), THROTTLE LEVERS SCREW
    WASHER, (.203 x .500 x .032), THROTTLE LEVERS SCREW
  • 17
    17-67297 PIN, Clevis, THROTTLE LEVERS TO THROTTLE LINK
    PIN, Clevis, THROTTLE LEVERS TO THROTTLE LINK
  • 18
    12-89302 WASHER, (.203 x .406 x .040), CLEVIS PIN
    WASHER, (.203 x .406 x .040), CLEVIS PIN
  • 19
    18-26953 COTTER PIN, CLEVIS PIN
    COTTER PIN, CLEVIS PIN
