GEAR HOUSING ASSEMBLY, COMPLETE (RIGHT HAND ROTATION) для Mercury - 800 (6 CYL.) 1335465 THRU 1398629

№

Артикул

Название
-

1620-1748A4 GEAR HOUSING ASSEMBLY, COMPLETE (STANDARD SHAFT)

GEAR HOUSING ASSEMBLY, COMPLETE (STANDARD SHAFT)

0 ₽
-

1620-1748A5 GEAR HOUSING ASSEMLBY, COMPLETE (LONG SHAFT)

GEAR HOUSING ASSEMLBY, COMPLETE (LONG SHAFT)

0 ₽
1

1620-1748A1 GEAR HOUSING ASSEMBLY

GEAR HOUSING ASSEMBLY

0 ₽
2

31-62091T BEARING, ROLLER - PROPELLER SHAFT

BEARING, ROLLER - PROPELLER SHAFT

6 670 ₽
3

31-32898T BEARING, ROLLER - DRIVE SHAFT

BEARING, ROLLER - DRIVE SHAFT

6 110 ₽
4

16-8M0133358 STUD, GEAR HOUSING TO DRIVE SHAFT HOUSING (2")

STUD, GEAR HOUSING TO DRIVE SHAFT HOUSING (2")

0 ₽
5

16-57935 STUD, GEAR HOUSING TO DRIVE SHAFT HOUSING (3")

STUD, GEAR HOUSING TO DRIVE SHAFT HOUSING (3")

0 ₽
6

16-68202 STUD, WATER PUMP BASE AND BODY TO GEAR HOUSING (3")

STUD, WATER PUMP BASE AND BODY TO GEAR HOUSING (3")

2 220 ₽
7

16-29974 STUD, WATER PUMP BASE AND BODY TO GEAR HOUSING (3 5/16")

STUD, WATER PUMP BASE AND BODY TO GEAR HOUSING (3 5/16")

0 ₽
7

16-8M0034463 STUD, WATER PUMP BASE AND BODY TO GEAR HOUSING (3 7/16")

STUD, WATER PUMP BASE AND BODY TO GEAR HOUSING (3 7/16")

670 ₽
8

45-30234 DRIVE SHAFT (STANDARD)

DRIVE SHAFT (STANDARD)

0 ₽
8

45-30220 DRIVE SHAFT (LONG)

DRIVE SHAFT (LONG)

0 ₽
9

43-29961 GEAR, PINION - DRIVE SHAFT

GEAR, PINION - DRIVE SHAFT

0 ₽
10

12-22025 WASHER, PINION GEAR TO RETIANING NUT

WASHER, PINION GEAR TO RETIANING NUT

0 ₽
11

11-82671317 NUT, PINION GEAR RETAINING

NUT, PINION GEAR RETAINING

280 ₽
12

15-30278A1 SHIM, DRIVE SHAFT BALL BEARING TO GEAR HOUSING (.002-3-5-10)

SHIM, DRIVE SHAFT BALL BEARING TO GEAR HOUSING (.002-3-5-10)

0 ₽
13

30-63326T BEARING, BALL - DRIVE SHAFT

BEARING, BALL - DRIVE SHAFT

2 530 ₽
14

53-30262 RING, RETAINING - BALL BEARING

RING, RETAINING - BALL BEARING

0 ₽
15

25-26855 "O" RING, WATER PUMP BASE

"O" RING, WATER PUMP BASE

150 ₽
16

46-30214A1 WATER PUMP BASE ASSEMBLY

WATER PUMP BASE ASSEMBLY

0 ₽
17

26-26226 OIL SEAL, WATER PUMP BASE

OIL SEAL, WATER PUMP BASE

0 ₽
18

17-29596T PIN, DOWEL WATER PUMP BASE TO BODY

PIN, DOWEL WATER PUMP BASE TO BODY

1 190 ₽
19

27-30216 GASKET, LOWER - WATER PUMP BASE TO FACE PLATE

GASKET, LOWER - WATER PUMP BASE TO FACE PLATE

0 ₽
20

30215 PLATE, FACE - WATER PUMP BASE TO BODY

PLATE, FACE - WATER PUMP BASE TO BODY

0 ₽
21

27-30933 GASKET, UPPER - FACE PLATE TO WATER PUMP BODY

GASKET, UPPER - FACE PLATE TO WATER PUMP BODY

0 ₽
22

46-30931A1 WATER PUMP BODY ASSEMBLY (SEE NOTE BELOW)

WATER PUMP BODY ASSEMBLY (SEE NOTE BELOW)

0 ₽
23

30915 INSERT, WATER PUMP BODY

INSERT, WATER PUMP BODY

9 620 ₽
24

26-16977 OIL SEAL, WATER PUMP BODY

OIL SEAL, WATER PUMP BODY

1 550 ₽
25

47-89984T4 IMPELLER, WATER PUMP

IMPELLER, WATER PUMP

2 670 ₽
26

17-8M0034466 PIN, IMPELLER DRIVE

PIN, IMPELLER DRIVE

420 ₽
--

25-20273 RING, RUBBER - WATER INLET TUBE

RING, RUBBER - WATER INLET TUBE

200 ₽
27

22-26220A1 WATER VALVE AND ADAPTOR ASSEMBLY

WATER VALVE AND ADAPTOR ASSEMBLY

0 ₽
28

21-26491 VALVE, WATER

VALVE, WATER

0 ₽
29

54-26492 CLAMP, WATER VALVE TO ADAPTOR

CLAMP, WATER VALVE TO ADAPTOR

0 ₽
30

15-21158A1 SHIM, VALVE ADAPTOR TO WATER PUMP BASE (.003-5-10)

SHIM, VALVE ADAPTOR TO WATER PUMP BASE (.003-5-10)

0 ₽
31

13-26993 LOCKWASHER, WATER PUMP BODY STUDS (5/16")

LOCKWASHER, WATER PUMP BODY STUDS (5/16")

140 ₽
32

11-28770 NUT, WATER PUMP BODY STUDS (5/16")

NUT, WATER PUMP BODY STUDS (5/16")

110 ₽
33

13-26992 LOCKWASHER, WATER PUMP BODY STUDS (1/4)

LOCKWASHER, WATER PUMP BODY STUDS (1/4)

70 ₽
34

11-29598 NUT, WATER PUMP BODY STUDS (1/4)

NUT, WATER PUMP BODY STUDS (1/4)

150 ₽
35

25-30271 RING, RUBBER - CENTRIFUGAL SLINGER (DRIVE SHAFT)

RING, RUBBER - CENTRIFUGAL SLINGER (DRIVE SHAFT)

150 ₽
36

26-38970 SEAL, RUBBER - WATER PUMP BODY

SEAL, RUBBER - WATER PUMP BODY

340 ₽
37

23-29804T SLEEVE, WATER INLET TUBE GUIDE

SLEEVE, WATER INLET TUBE GUIDE

630 ₽
38

26-29971 SEAL, RUBBER - WATER INTAKE TUBE TO GEAR HOUSING

SEAL, RUBBER - WATER INTAKE TUBE TO GEAR HOUSING

0 ₽
39

32-29958A1 WATER INTAKE TUBE ASSEMLBY (LOWER)

WATER INTAKE TUBE ASSEMLBY (LOWER)

0 ₽
40

23-29966 SLEEVE, WATER INTAKE TUBE

SLEEVE, WATER INTAKE TUBE

0 ₽
41

44-30112 SHAFT, PROPELLER

SHAFT, PROPELLER

0 ₽
42

43-30113 GEAR, PROPELLER

GEAR, PROPELLER

0 ₽
43

17-26200 PIN, DOWEL - PROPELLER GEAR TO SHAFT

PIN, DOWEL - PROPELLER GEAR TO SHAFT

0 ₽
--

53-28757 RING, SNAP - DOWEL PIN RETAINING

RING, SNAP - DOWEL PIN RETAINING

0 ₽
44

15-29955A1 SHIM, THRUST RING TO GEAR HOUSING (.002-3-5-10)

SHIM, THRUST RING TO GEAR HOUSING (.002-3-5-10)

2 520 ₽
45

12-29956 RING, THRUST - PROPELLER SHAFT

RING, THRUST - PROPELLER SHAFT

0 ₽
46

30-20840 BEARING, BALL - PROPELLER GEAR

BEARING, BALL - PROPELLER GEAR

0 ₽
47

14-28445 TAB WASHER, BEARING RETAINING NUT

TAB WASHER, BEARING RETAINING NUT

0 ₽
48

11-29712 NUT, BALL BEARING RETAINING

NUT, BALL BEARING RETAINING

0 ₽
49

25-29976 "O" RING, BEARING CARRFIER

"O" RING, BEARING CARRFIER

480 ₽
50

30218A1 BEARING CARRIER ASSEMBLY

BEARING CARRIER ASSEMBLY

0 ₽
51

31-29610 BEARING, ROLLER - BEARING CARRIER

BEARING, ROLLER - BEARING CARRIER

0 ₽
52

26-29593 OIL SEAL, BEARING CARRIER

OIL SEAL, BEARING CARRIER

0 ₽
53

17-30282 PIN, LOCATING - BEARING CARRIER

PIN, LOCATING - BEARING CARRIER

420 ₽
54

29621 RACE, INNER - CARRIER ROLLER BEARING

RACE, INNER - CARRIER ROLLER BEARING

0 ₽
55

23-29588 SPACER, INNER - BEARING CARRIER

SPACER, INNER - BEARING CARRIER

0 ₽
56

29609 SLEEVE, SEALING - PROPELLER SHAFT

SLEEVE, SEALING - PROPELLER SHAFT

0 ₽
57

25-23145 "O" RING, SEALING SLEEVE

"O" RING, SEALING SLEEVE

140 ₽
58

12-29957 WASHER, GEAR HOUSING COVER

WASHER, GEAR HOUSING COVER

0 ₽
59

30114 COVER, GEAR HOUSING

COVER, GEAR HOUSING

0 ₽
60

10-29941 SCREW, SET-GEAR HOUSING COVER LOCKING

SCREW, SET-GEAR HOUSING COVER LOCKING

0 ₽
61

19-29944 PLUG, NYLON - COVER SET SCREW

PLUG, NYLON - COVER SET SCREW

0 ₽
62

10-29608 SCREW, GEAR HOUSING FLUSHING HOLE
TO PROVIDE PROPER DRAINAGE, ORDER 10-31498 SCREW IN PLACE OF 10-30608 SCREW. 10-31498 SCREW HAS A 1/16" HOLE DRILLED THROUGH CENTER.

SCREW, GEAR HOUSING FLUSHING HOLE
TO PROVIDE PROPER DRAINAGE, ORDER 10-31498 SCREW IN PLACE OF 10-30608 SCREW. 10-31498 SCREW HAS A 1/16" HOLE DRILLED THROUGH CENTER.

0 ₽
63

26-29612 SEAL, GEAR HOUSING FLUSHING HOLE

SEAL, GEAR HOUSING FLUSHING HOLE

280 ₽
64

27-29586 GASKET, GEAR HOUSING FLUSHING HOLE SCREW

GASKET, GEAR HOUSING FLUSHING HOLE SCREW

90 ₽
65

10-28653 SCREW, GEAR HOUSING VENT
ON LATER PRODUCTION ENGINES, THE 10-28653 VENT SCREW AND 12-20262 WASHER ARE REPLACED BY 10-28634 SCREW AND 12-20260 WASHER.

SCREW, GEAR HOUSING VENT
ON LATER PRODUCTION ENGINES, THE 10-28653 VENT SCREW AND 12-20262 WASHER ARE REPLACED BY 10-28634 SCREW AND 12-20260 WASHER.

150 ₽
66

19643 WASHER, GEAR HOUSING VENT SCREW
ON LATER PRODUCTION ENGINES, THE 10-28653 VENT SCREW AND 12-20262 WASHER ARE REPLACED BY 10-28634 SCREW AND 12-20260 WASHER.

WASHER, GEAR HOUSING VENT SCREW
ON LATER PRODUCTION ENGINES, THE 10-28653 VENT SCREW AND 12-20262 WASHER ARE REPLACED BY 10-28634 SCREW AND 12-20260 WASHER.

70 ₽
67

10-79953Q04 SCREW, GEAR HOUSING GREASE FILLER HOLE
ON LATER PRODUCTION ENGINES, THE 10-28653 VENT SCREW AND 12-20262 WASHER ARE REPLACED BY 10-28634 SCREW AND 12-20260 WASHER.

SCREW, GEAR HOUSING GREASE FILLER HOLE
ON LATER PRODUCTION ENGINES, THE 10-28653 VENT SCREW AND 12-20262 WASHER ARE REPLACED BY 10-28634 SCREW AND 12-20260 WASHER.

1 000 ₽
68

12-191833 WASHER, GEAR HOUSING GREASE FILLER HOLE SCREW
ON LATER PRODUCTION ENGINES, THE 10-28653 VENT SCREW AND 12-20262 WASHER ARE REPLACED BY 10-28634 SCREW AND 12-20260 WASHER.

WASHER, GEAR HOUSING GREASE FILLER HOLE SCREW
ON LATER PRODUCTION ENGINES, THE 10-28653 VENT SCREW AND 12-20262 WASHER ARE REPLACED BY 10-28634 SCREW AND 12-20260 WASHER.

60 ₽
69

29583A1 THRUST HUB AND WASHER ASSEMBLY

THRUST HUB AND WASHER ASSEMBLY

0 ₽
70

12-29590 WASHER, CUPPED - THRUST HUB

WASHER, CUPPED - THRUST HUB

0 ₽
71

12-29585 WASHER, CUPPED - PROPELLER SHAFT

WASHER, CUPPED - PROPELLER SHAFT

0 ₽
72

11-29594 NUT, PROPELLER

NUT, PROPELLER

0 ₽
73

29803 CAP, PROPELLER NUT - BROWN

CAP, PROPELLER NUT - BROWN

0 ₽
74

30427A1 WATER PICK-UP ASSEMBLY, GEAR HOUSING

WATER PICK-UP ASSEMBLY, GEAR HOUSING

0 ₽
75

10-30586 SCREW, WATER PICK-UP TO GEAR HOUSING (5/8")

SCREW, WATER PICK-UP TO GEAR HOUSING (5/8")

0 ₽
76

27-30296 GASKET, WATER PICK-UP TO GEAR HOUSING

GASKET, WATER PICK-UP TO GEAR HOUSING

0 ₽
77

10-30298 SCREW, WATER PICK-UP TO GEAR HOUSING (2 3/4")

SCREW, WATER PICK-UP TO GEAR HOUSING (2 3/4")

0 ₽
78

13-26993 LOCKWASHER, WATER PICK-UP FASTENING SCREW

LOCKWASHER, WATER PICK-UP FASTENING SCREW

140 ₽
79

10-30206 SCREW, GEAR HOUSING TO DRIVE SHAFT HOUSING (1")

SCREW, GEAR HOUSING TO DRIVE SHAFT HOUSING (1")

290 ₽
