INTAKE MANIFOLD AND THROTTLE LINKAGE для Mercruiser - 470 (2 BBL.) MERCURY 224 I/L4 1983-1984 6218037 THRU 6916778
-
№АртикулНазвание
-
189953A2 MANIFOLD ASSEMBLY, IntakeMANIFOLD ASSEMBLY, Intake
-
222-36382 FITTING, (.250-18 x .62) BrassFITTING, (.250-18 x .62) Brass
-
310-28642 SCREW, (#2 x 0.25)SCREW, (#2 x 0.25)
-
427-70905 GASKET, INTAKE MANIFOLDGASKET, INTAKE MANIFOLD
-
510-68101 SCREW, (.375-16 x 1.375), INTAKE MANIFOLD TO CYLINDER HEADSCREW, (.375-16 x 1.375), INTAKE MANIFOLD TO CYLINDER HEAD
-
612-25909 WASHER, (.406 x .812 x .065), INTAKE MANIFOLD SCREWWASHER, (.406 x .812 x .065), INTAKE MANIFOLD SCREW
-
722-73817 CONNECTOR, (90 Degree), INTAKE MANIFOLDCONNECTOR, (90 Degree), INTAKE MANIFOLD
-
832-89713 HOSE, INTAKE MANIFOLD TO RESERVOIRHOSE, INTAKE MANIFOLD TO RESERVOIR
-
954-815504104 CLAMP, HOSE ATTACHINGCLAMP, HOSE ATTACHING
-
1078801T LEVER, INTERMEDIATE THROTTLELEVER, INTERMEDIATE THROTTLE
-
1112-35950 WASHER, (.273 x .437 x .031) Stainless Steel, INTERMEDIATE THROTTLE STUDWASHER, (.273 x .437 x .031) Stainless Steel, INTERMEDIATE THROTTLE STUD
-
1212-30164 WASHER, (.192 x .375 x .0312) Stainless Steel, INTERMIDIATE STUDWASHER, (.192 x .375 x .0312) Stainless Steel, INTERMIDIATE STUD
-
1311-20110 NUT, (#10-32), INTERMEDIATE THROTTLE STUDNUT, (#10-32), INTERMEDIATE THROTTLE STUD
-
1410-38507 SCREW, (5/16-18 x 1.313), LEVER TO INTAKE MANIFOLDSCREW, (5/16-18 x 1.313), LEVER TO INTAKE MANIFOLD
-
1512-20553 WASHER, (.406 x .734 x .063), LEVER SCREWWASHER, (.406 x .734 x .063), LEVER SCREW
-
1612-57792 WASHER, LEVER SCREWWASHER, LEVER SCREW
-
1727947 SWIVEL, LINKAGESWIVEL, LINKAGE
-
1864804 LINK RODLINK ROD
-
1963145A1 LINK ROD ASSEMBLYLINK ROD ASSEMBLY
-
2038983 SWIVEL, LINKAGE-CARBURETORSWIVEL, LINKAGE-CARBURETOR
-
2112-35950 WASHER, (.273 x .437 x .031) Stainless Steel, SWIVEL LINKAGE-CARBURETORWASHER, (.273 x .437 x .031) Stainless Steel, SWIVEL LINKAGE-CARBURETOR
-
2212-30164 WASHER, (.192 x .375 x .0312) Stainless Steel, SWIVEL LINKAGE-CARBURETORWASHER, (.192 x .375 x .0312) Stainless Steel, SWIVEL LINKAGE-CARBURETOR
-
2311-20110 NUT, (#10-32), SWIVEL LINKAGE-CARBURETORNUT, (#10-32), SWIVEL LINKAGE-CARBURETOR
-
2416-38525 STUD, THROTTLE CABLE ANCHORSTUD, THROTTLE CABLE ANCHOR
-
2512-24664 WASHER, (M4 x 20), THROTTLE CABLE ANCHOR STUDWASHER, (M4 x 20), THROTTLE CABLE ANCHOR STUD
-
2611-826709109 NUT, (.250-28), THROTTLE CABLE ANCHOR STUDNUT, (.250-28), THROTTLE CABLE ANCHOR STUD
-
2710-64969 SCREW, THROTTLE STOPSCREW, THROTTLE STOP
-
2811-33122 NUT, THROTTLE STOP SCREWNUT, THROTTLE STOP SCREW
-
2932-76326 HOSE, INTAKE MANIFOLD TO WATER PUMPHOSE, INTAKE MANIFOLD TO WATER PUMP
-
3054-815504220 CLAMP, HOSE TO WATER PUMPCLAMP, HOSE TO WATER PUMP
-
3154-815504228 CLAMP, HOSE TO INTAKE MANIFOLDCLAMP, HOSE TO INTAKE MANIFOLD
-
3232-89655 HOSE, INTAKE MANIFOLDHOSE, INTAKE MANIFOLD
-
3354-815504228 CLAMP, HOSE TO INTAKE MANIFOLDCLAMP, HOSE TO INTAKE MANIFOLD
