WIRING HARNESS для Ktm 150 XCW - 2018 года выпуска

  • №
    Артикул
    Название
  • 2
    54811075800 WIRING HARNESS 200/300 XC-W
    WIRING HARNESS 200/300 XC-W
  • 4
    0017060305 SPECIAL SCREW K60X30 WS=6
    SPECIAL SCREW K60X30 WS=6
  • 5
    44011076140 CABLE TIE 140/2,5MM BLACK
    CABLE TIE 140/2,5MM BLACK
  • 5
    44011076200 CABLE TIE 200/3,6MM BLACK
    CABLE TIE 200/3,6MM BLACK
  • 5
    44011076305 CABLE TIE 300/4,8MM BLACK
    CABLE TIE 300/4,8MM BLACK
  • 6
    59001092050 SPECIAL SCREW M6X12,5
    SPECIAL SCREW M6X12,5
  • 10
    0021050003 WASHER DIN9021-A 5,3
    WASHER DIN9021-A 5,3
  • 13
    80011034000 VOLTAGE REGULATOR
    VOLTAGE REGULATOR
  • 14
    79011055100 BATTERY BOX
    BATTERY BOX
  • 18
    60308006000 COLLAR BUSHING 6,2X9,2X15X12,5
    COLLAR BUSHING 6,2X9,2X15X12,5
  • 19
    0017060206 SCREW F. PLASTIC K60X20AL SW6
    SCREW F. PLASTIC K60X20AL SW6
  • 20
    51639231000 ELECTRONIC BOX 150 18
    ELECTRONIC BOX 150 18
  • 23
    57013072000 WIRING HOLDER 12MM
    WIRING HOLDER 12MM
  • 23
    57013072100 WIRING HOLDER 16MM
    WIRING HOLDER 16MM
  • 26
    77311953000 LITHIUM ION BATTERY 5S
    LITHIUM ION BATTERY 5S
  • 27
    58411097100 GROUND CABLE D=6MM L=140MM
    GROUND CABLE D=6MM L=140MM
  • 28
    58411098100 CONTACT WASHER M6 VSV-K6
    CONTACT WASHER M6 VSV-K6
  • 30
    0025060126 HH COLLAR SCREW M6X12
    HH COLLAR SCREW M6X12
  • 31
    79011056100 BATTERY BOX SUPPORT
    BATTERY BOX SUPPORT
  • 32
    54839032200 WIRING HARNESS FOR CDI 2-ST.
    WIRING HARNESS FOR CDI 2-ST.
  • 34
    58111076000 CABLE SUPPORT KHS NR.150-47610
    CABLE SUPPORT KHS NR.150-47610
  • 35
    0023060123 COLLAR SCREW M6X12
    COLLAR SCREW M6X12
  • 37
    59003001099 METAMOLL 90X45X3MM
    METAMOLL 90X45X3MM
  • 40
    58011109110 FUSE 10A
    FUSE 10A
  • 56
    58711086000 WIRING HARNESS BATTERY DUKE
    WIRING HARNESS BATTERY DUKE
  • 58
    58211058000 STARTER RELAY 12V
    STARTER RELAY 12V
  • 88
    0902060083 AH OVAL SCREW ISO 7380 M 6X8
    AH OVAL SCREW ISO 7380 M 6X8
