FRONT FORK TRIPLE CLAMP для Ktm 65 XC - 2009 года выпуска

  • №
    Артикул
    Название
  • 1
    46201000133 FRONT FORK USD D035MM
    FRONT FORK USD D035MM
  • 2
    0025060306 HH COLLAR SCREW M6X30
    HH COLLAR SCREW M6X30
  • 5
    0025080306 HH COLLAR SCREW M8X30
    HH COLLAR SCREW M8X30
  • 6
    0912100250 AH SCREW DIN6912-M10X25,10.9,L
    AH SCREW DIN6912-M10X25,10.9,L
  • 31
    77051116 BOT.TRIPLE CLAMP + FORK TUBE
    BOT.TRIPLE CLAMP + FORK TUBE
  • 34
    7501478 TOP TRIPLE CLAMP
    TOP TRIPLE CLAMP
  • 38
    50301038000 HANDLEBAR CLAMP D=22MM
    HANDLEBAR CLAMP D=22MM
  • 39
    59001039000 HANDLEBAR SUPPORT 22MM 2T
    HANDLEBAR SUPPORT 22MM 2T
  • 42
    59030029000 HH NUT M20X1,5 WS=27 RIGHT
    HH NUT M20X1,5 WS=27 RIGHT
  • 43
    49001086000 COVERING CAP
    COVERING CAP
  • 44
    0770021300 O-RING 40,94X2,62 NBR70
    O-RING 40,94X2,62 NBR70
  • 45
    49001081000 TAPERED ROLLER BEARING 32004X
    TAPERED ROLLER BEARING 32004X
  • 46
    46001086000 PROTECTION RING 20,1X39X5
    PROTECTION RING 20,1X39X5
  • 47
    0770360030 O-RING 36,00X3,00 NBR
    O-RING 36,00X3,00 NBR
  • 91
    59001092050 SPECIAL SCREW M6X12,5
    SPECIAL SCREW M6X12,5
  • 92
    46101092000 FORK PROTECTION L/S 65SX
    FORK PROTECTION L/S 65SX
  • 93
    46101093000 FORK PROTECTION R/S 65SX
    FORK PROTECTION R/S 65SX
  • 94
    54601085000 BRAKE HOSE CLAMP MARZOCCHI
    BRAKE HOSE CLAMP MARZOCCHI
  • 95
    0025050166 HH COLLAR SCREW M5X16
    HH COLLAR SCREW M5X16
  • 96
    0985050003 SELF LOCKING NUT DIN0985-M 5
    SELF LOCKING NUT DIN0985-M 5
