MASK FENDERS для Ktm 690 SMC - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    7650800100004 HEADLIGHT MASK
    HEADLIGHT MASK
  • 2
    0025050126 HH COLLAR SCREW M5X12 TX30
    HH COLLAR SCREW M5X12 TX30
  • 3
    54603048200 RANGE CHANGE METAL NUT M5
    RANGE CHANGE METAL NUT M5
  • 4
    7730821000004 FENDER FRONT SMR
    FENDER FRONT SMR
  • 5
    62508009000 COLLAR BUSHING 7,2X10X15X8,5
    COLLAR BUSHING 7,2X10X15X8,5
  • 6
    0024060206 HH COLLAR SCREW M6X20 TX30
    HH COLLAR SCREW M6X20 TX30
  • 7
    60012080000 SIDE REFLECTOR YELLOW ONLY FOR USA+AUS+UK
    SIDE REFLECTOR YELLOW ONLY FOR USA+AUS+UK
  • 8
    76513025000 BRAKE HOSE GUIDE
    BRAKE HOSE GUIDE
  • 10
    7650801300004 REAR FENDER
    REAR FENDER
  • 11
    0025060126 HH COLLAR SCREW M6X12 TX30
    HH COLLAR SCREW M6X12 TX30
  • 14
    76512008000 HAND GRIP L/S
    HAND GRIP L/S
  • 15
    76512009000 HAND GRIP R/S
    HAND GRIP R/S
  • 16
    0019080756 COUNTERSUNK SCREW ISA45 M8X75
    COUNTERSUNK SCREW ISA45 M8X75
  • 17
    76508116000 NUMBER PLATE CARRIER TOP
    NUMBER PLATE CARRIER TOP
  • 18
    0025080256 HH COLLAR SCREW M8X25 TX40
    HH COLLAR SCREW M8X25 TX40
  • 20
    0017060203 EJOT PT SCREW K60X20 WS=6
    EJOT PT SCREW K60X20 WS=6
  • 21
    0017060303 SPECIAL SCREW T60 6X30 WS=6
    SPECIAL SCREW T60 6X30 WS=6
  • 22
    76514064000 COVER
    COVER
  • 23
    58214069051 RUBBER GROMMET 16X10,8X3
    RUBBER GROMMET 16X10,8X3
  • 24
    75014010050 COLLAR BUSHING 6,1X8,1X14X8
    COLLAR BUSHING 6,1X8,1X14X8
  • 27
    76508043050 COLLAR BUSHING
    COLLAR BUSHING
  • 30
    60012081200 LICENCE FITTING
    LICENCE FITTING
  • 31
    0024060156 HH COLLAR SCREW M6X15 TX30
    HH COLLAR SCREW M6X15 TX30
  • 32
    0021060003 WASHER DIN9021-A 6,4
    WASHER DIN9021-A 6,4
  • 33
    0985060003 SELF LOCK. NUT DIN0985-M 6
    SELF LOCK. NUT DIN0985-M 6
  • 34
    0966050163 OVAL HEAD SCREW DIN0966-M 5X16
    OVAL HEAD SCREW DIN0966-M 5X16
  • 35
    40006006000 WASHER 6MM
    WASHER 6MM
  • 36
    0125050003 WASHER DIN0125-A 5,3
    WASHER DIN0125-A 5,3
  • 37
    0985050003 SELF LOCKING NUT DIN0985-M 5
    SELF LOCKING NUT DIN0985-M 5
  • 38
    58412080000 REFLECTOR RED
    REFLECTOR RED
  • 39
    58412080050 BRACKET FOR REFLECTOR
    BRACKET FOR REFLECTOR
  • 40
    62512081000 BRACKET SIDE REFLECTOR
    BRACKET SIDE REFLECTOR
  • 41
    16512180100 SIDE REFLECTOR RED REAR ONLY FOR USA
    SIDE REFLECTOR RED REAR ONLY FOR USA
