FRAME SUB FRAME ENGINE GUARD для Ktm 950 ADVENTURE ORANGE - 2006 года выпуска

  • №
    Артикул
    Название
  • 1*
    6000300110030 FRAME "FA06" 950 ADV.
    FRAME "FA06" 950 ADV.
  • 2
    54603048000 RANGE CHANGE METAL NUT M8
    RANGE CHANGE METAL NUT M8
  • 3
    54603048100 RANGE CHANGE METAL NUT M6
    RANGE CHANGE METAL NUT M6
  • 4
    0015080403 HH COLLAR SCREW M 8X40 WS=10
    HH COLLAR SCREW M 8X40 WS=10
  • 5
    58403060000 CHAIN ROLL 12X29X22,5
    CHAIN ROLL 12X29X22,5
  • 6
    58403060065 BUSH CHAIN ROLL 8X12X23
    BUSH CHAIN ROLL 8X12X23
  • 7
    36003014000 LOCK WASHER 8MM
    LOCK WASHER 8MM
  • 8*
    60004076100 CHAIN SLIDING BLOCK
    CHAIN SLIDING BLOCK
  • 9*
    0017060204 EJOT PT SCREW K60X20 ALU WS=6
    EJOT PT SCREW K60X20 ALU WS=6
  • 10*
    58303070100 BUMP RUBBER M8X25MM
    BUMP RUBBER M8X25MM
  • 11
    0934080003 HEXAGON NUT DIN0934-M 8
    HEXAGON NUT DIN0934-M 8
  • 12
    60003088000 PLASTIC CAP FOR M6
    PLASTIC CAP FOR M6
  • 13
    54630044000 COLLAR NUT M10 WS=13
    COLLAR NUT M10 WS=13
  • 14
    60003013000 ENGINE BRAC. SCREW M10X172
    ENGINE BRAC. SCREW M10X172
  • 15
    60003014000 ENGINE BRAC. SCREW M10X206
    ENGINE BRAC. SCREW M10X206
  • 16
    60003005000 ENGINE SUPPORT LEFT
    ENGINE SUPPORT LEFT
  • 17
    60003006000 ENGINE SUPPORT RIGHT
    ENGINE SUPPORT RIGHT
  • 18
    60003098000 RUBBER SLEEVE
    RUBBER SLEEVE
  • 19
    0015100243 HH COLLAR SCREW M10X24 WS=13
    HH COLLAR SCREW M10X24 WS=13
  • 20
    54310086100 SELF LOCKING NUT M10 CU WS=14
    SELF LOCKING NUT M10 CU WS=14
  • 21
    60003002000 SUB FRAME ALUMINIUM LC8
    SUB FRAME ALUMINIUM LC8
  • 22
    60003004027 FL.HEAD SCREW M10X1,25 L=27
    FL.HEAD SCREW M10X1,25 L=27
  • 23
    60003001051 COLLAR BUSHING 10X15X25X4
    COLLAR BUSHING 10X15X25X4
  • 27
    60003087000 SPLASH PROTECTOR FRAME
    SPLASH PROTECTOR FRAME
  • 30
    60003091000 UNDERRIDE PROTECTION
    UNDERRIDE PROTECTION
  • 31
    60003092000 UNDERRIDE PROTECTION LEFT
    UNDERRIDE PROTECTION LEFT
  • 32
    60003093000 UNDERRIDE PROTECTION RIGHT
    UNDERRIDE PROTECTION RIGHT
  • 33
    60003094000 LOWER TANK HOLDER FRONT
    LOWER TANK HOLDER FRONT
  • 34
    60003097000 COLLAR SCREW M8
    COLLAR SCREW M8
  • 35
    60003095000 CAGE NUT M6 SL 4MM
    CAGE NUT M6 SL 4MM
  • 36
    0014060153 HH COLLAR SCREW M 6X15 WS=8
    HH COLLAR SCREW M 6X15 WS=8
  • 37
    60003096000 VIBRATION DAMPER
    VIBRATION DAMPER
  • 38
    0015080163 HH COLLAR SCREW M 8X16 WS=10
    HH COLLAR SCREW M 8X16 WS=10
  • 39*
    60003040033 FOOTREST L/S+R/S CPL.
    FOOTREST L/S+R/S CPL.
  • 40
    59003040250 FOOT PED L/S SILVER
    FOOT PED L/S SILVER
  • 41
    59003041250 FOOT PED R/S SILVER
    FOOT PED R/S SILVER
