BRAKE CALIPER FRONT для Ktm 65 SX - 2006 года выпуска

  • №
    Артикул
    Название
  • 10
    46113010100 BRAKE HOSE FRONT
    BRAKE HOSE FRONT
  • 11
    0770080019 O-RING 8,00X1,00 EPDM
    O-RING 8,00X1,00 EPDM
  • 15
    47013015000 BRAKE CALIPER FR. CPL.
    BRAKE CALIPER FR. CPL.
  • 18
    46113018000 RETAINING SPRING
    RETAINING SPRING
  • 20
    47013020000 BLEEDER SCREW M6
    BLEEDER SCREW M6
  • 21
    47013021000 CAP FOR BLEEDER SCREW
    CAP FOR BLEEDER SCREW
  • 23
    0770100019 O-RING 10X1 EPDM
    O-RING 10X1 EPDM
  • 25
    47013125000 HOLLOW SCREW M8X38,8
    HOLLOW SCREW M8X38,8
  • 30
    46113030000 BRAKE PAD SET FRONT
    BRAKE PAD SET FRONT
  • 70
    0912060283 AH SCREW DIN0912-M 6X28
    AH SCREW DIN0912-M 6X28
  • 75
    0015080303 HH COLLAR SCREW M 8X30 WS=10
    HH COLLAR SCREW M 8X30 WS=10
  • 81
    46113019000 REPAIR KIT SEAL RING
    REPAIR KIT SEAL RING
  • 83
    0799040009 TAB WASHER DIN6799-RA 4,0
    TAB WASHER DIN6799-RA 4,0
  • 85
    46113125000 AH SCREW + CIRCLIP
    AH SCREW + CIRCLIP
