FRONT FORK для Ktm 640 ADVENTURE - 2005 года выпуска

  • №
    Артикул
    Название
  • 1
    14187A26LS FORK LEG L/S WP48
    FORK LEG L/S WP48
  • 2
    14187A26RS FORK LEG R/S WP48
    FORK LEG R/S WP48
  • 4
    0015080353 HH COLLAR SCREW M 8X35 WS=10
    HH COLLAR SCREW M 8X35 WS=10
  • 5
    0015080303 HH COLLAR SCREW M 8X30 WS=10
    HH COLLAR SCREW M 8X30 WS=10
  • 6
    0984100856 AH SCREW DIN6912-M10X85
    AH SCREW DIN6912-M10X85
  • 8
    60003088000 PLASTIC CAP
    PLASTIC CAP
  • 22
    58213010150 BRAKE HOSE GUIDE
    BRAKE HOSE GUIDE
  • 23
    0014060103 HH COLLAR SCREW M 6X10 WS=8
    HH COLLAR SCREW M 6X10 WS=8
  • 24
    60008019000 BRAKE HOSE GUIDE LOWER
    BRAKE HOSE GUIDE LOWER
  • 25
    50308052000 BUSH
    BUSH
  • 26
    0015060163 HH COLLAR SCREW M 6X16 WS=8
    HH COLLAR SCREW M 6X16 WS=8
  • 32
    58201032118 BOT.TRIPLE CLAMP X=18MM/D=60MM
    BOT.TRIPLE CLAMP X=18MM/D=60MM
  • 33
    50101033100 FORK TUBE L=244
    FORK TUBE L=244
  • 34
    58401034318 TOP TRIPLE CLAMP X=18MM/D=54MM
    TOP TRIPLE CLAMP X=18MM/D=54MM
  • 37
    50301036000 STEER.HEAD SCREW M20X1,5 WS=27
    STEER.HEAD SCREW M20X1,5 WS=27
  • 38
    59001038200 HANDLEBAR CLAMP D=28MM
    HANDLEBAR CLAMP D=28MM
  • 39
    59001039100 HANDLEBAR SUPPORT 28MM
    HANDLEBAR SUPPORT 28MM
  • 40
    56401042000 WASHER 10,5X32X2
    WASHER 10,5X32X2
  • 41
    56401040000 RUBBER BUSHING
    RUBBER BUSHING
  • 42
    56401142000 WASHER 10,5X31
    WASHER 10,5X31
  • 43
    0982100003 SELF LOCK.NUT DIN0982-M10 HIGH
    SELF LOCK.NUT DIN0982-M10 HIGH
  • 44
    58201041000 SPACER TUBE 10,2X12X62
    SPACER TUBE 10,2X12X62
  • 45
    59001043000 HANDLEBAR RISER
    HANDLEBAR RISER
  • 81
    54201081000 TAPERED ROLLER BEARING CPL.
    TAPERED ROLLER BEARING CPL.
  • 82
    54601084100 O-RING SUPPORT W. SEALING LIP
    O-RING SUPPORT W. SEALING LIP
  • 84
    54601184000 STEARING HEAD GASKET TOP
    STEARING HEAD GASKET TOP
  • 86
    54201086000 STEERING HEAD COVER
    STEERING HEAD COVER
