ENGINE CASE для Ktm 625 SXC - 2005 года выпуска`

№

Артикул

Название
1

5843000034423 ENGINE CASE CPL.W.BEAR.

ENGINE CASE CPL.W.BEAR.

340 ₽
5

50130027000 DOWEL 19 X15,1X12

DOWEL 19 X15,1X12

1 730 ₽
6

51030026100 DOWEL 17 X 14 X 12

DOWEL 17 X 14 X 12

1 550 ₽
7

50130010000 CRANK CASE BUSH

CRANK CASE BUSH

7 100 ₽
9

58033097000 NEEDLE BEARING HK 2216

NEEDLE BEARING HK 2216

3 770 ₽
10

58330011000 SHIFT MECHANISM SUPPORT

SHIFT MECHANISM SUPPORT

29 340 ₽
11

49030090000 DOWEL 9,8 X 7 X 10

DOWEL 9,8 X 7 X 10

290 ₽
15

56530017000 RETAINING PLATE

RETAINING PLATE

3 920 ₽
16

0991060166 FL.HEAD SCR.DIN7991-M6X16 10.9

FL.HEAD SCR.DIN7991-M6X16 10.9

320 ₽
18

0015080163 HH COLLAR SCREW M 8X16 WS=10

HH COLLAR SCREW M 8X16 WS=10

760 ₽
19

0603082121 SEAL RING CU DIN7603- 8X12X1

SEAL RING CU DIN7603- 8X12X1

760 ₽
20

58530039300 ENGI.CASE GASKET POLY. 0,43

ENGI.CASE GASKET POLY. 0,43

5 520 ₽
21

0985050103 OVAL HEAD SCR. DIN7985-M 5X10

OVAL HEAD SCR. DIN7985-M 5X10

150 ₽
23

0412174012 CYLIND.ROLL.NJ 203 ECP/C3

CYLIND.ROLL.NJ 203 ECP/C3

17 000 ₽
24

0625618050 BALL BEARING 61805 C3

BALL BEARING 61805 C3

11 860 ₽
26

60030064070 OIL JET 70 M6X0,75 WS8

OIL JET 70 M6X0,75 WS8

3 100 ₽
28

58440091000 STOP DISK 33 X 58 X 1,5

STOP DISK 33 X 58 X 1,5

1 220 ₽
30

5833010124423 CLUTCH COVER CPL. GREY

CLUTCH COVER CPL. GREY

30 640 ₽
31

58530025000 CLUTCH COVER GASKET

CLUTCH COVER GASKET

5 080 ₽
33

58030020100 PLUG CPL. M24X3

PLUG CPL. M24X3

1 080 ₽
34

0770191015 O-RING 19,00X3,00 NBR

O-RING 19,00X3,00 NBR

290 ₽
35

61030019050 CIRCLIP OIL LEVEL GLASS

CIRCLIP OIL LEVEL GLASS

150 ₽
36

59030019000 OIL LEVEL GLASS G 1777 Y

OIL LEVEL GLASS G 1777 Y

5 720 ₽
38

58333041000 BUMP RUBBER

BUMP RUBBER

2 160 ₽
39

58430047200 CHA.DAMPERSHEET 15/16T 92MM

CHA.DAMPERSHEET 15/16T 92MM

5 430 ₽
40

58730047100 CHAIN DAMPERSHEET 17T 92MM

CHAIN DAMPERSHEET 17T 92MM

4 410 ₽
42

58430060100 SPROCKET COVER

SPROCKET COVER

2 680 ₽
43

54613038150 BUSHING 6,5X8X11

BUSHING 6,5X8X11

850 ₽
44

58030021000 OILDRAIN PLUG W.MAG. M 12X1,5

OILDRAIN PLUG W.MAG. M 12X1,5

2 800 ₽
45

58038017100 CU-SEAL RING DIN7603-22X27X2

CU-SEAL RING DIN7603-22X27X2

590 ₽
46

58038019100 OIL DRAIN PLUG M22X1,5

OIL DRAIN PLUG M22X1,5

8 790 ₽
47

58038022000 CU-SEAL RING DIN7603-12X18X1,5

CU-SEAL RING DIN7603-12X18X1,5

440 ₽
48

0908120153 PLUG DIN0908-M12X1,5

PLUG DIN0908-M12X1,5

850 ₽
50

58038023300 PRESSURE SPRING L=25MM D=1MM

PRESSURE SPRING L=25MM D=1MM

1 200 ₽
51

58038028000 VALVE PISTON D=10MM

VALVE PISTON D=10MM

10 200 ₽
55

58430099200 GASKET SET

GASKET SET

79 700 ₽
60

0015060253 HH COLLAR SCREW M 6X25 WS=8

HH COLLAR SCREW M 6X25 WS=8

560 ₽
61

0015060303 HH COLLAR SCREW M 6X30 WS=8

HH COLLAR SCREW M 6X30 WS=8

560 ₽
62

0015060353 HH COLLAR SCREW M 6X35 WS=8

HH COLLAR SCREW M 6X35 WS=8

560 ₽
63

0015060403 HH COLLAR SCREW M 6X40 WS=8

HH COLLAR SCREW M 6X40 WS=8

500 ₽
66

0015060553 HH COLLAR SCREW M 6X55 WS=8

HH COLLAR SCREW M 6X55 WS=8

470 ₽
68

0015060653 HH COLLAR SCREW M 6X65 WS=8

HH COLLAR SCREW M 6X65 WS=8

320 ₽
71

0015060303 HH COLLAR SCREW M 6X30 WS=8

HH COLLAR SCREW M 6X30 WS=8

560 ₽
71

0015060353 HH COLLAR SCREW M 6X35 WS=8

HH COLLAR SCREW M 6X35 WS=8

560 ₽
72

0603082131 COPPER GASK.DIN7603- 8,2X13X1

COPPER GASK.DIN7603- 8,2X13X1

320 ₽
73

0908080013 PLUG M8X1 DIN 908

PLUG M8X1 DIN 908

700 ₽
