FRONT FORK для Ktm 450 STEVE RAMON - 2005 года выпуска

  • №
    Артикул
    Название
  • 1
    14187A05LS FORK LEG US WP48
    FORK LEG US WP48
  • 2
    14187A05RS FORK LEG R/S WP48
    FORK LEG R/S WP48
  • 3
    0015080253 HH COLLAR SCREW M 8X25 WS=10
    HH COLLAR SCREW M 8X25 WS=10
  • 4
    0015080353 HH COLLAR SCREW M 8X35 WS=10
    HH COLLAR SCREW M 8X35 WS=10
  • 6
    0912100356 AH SCREW DIN6912-M10X35 10.9
    AH SCREW DIN6912-M10X35 10.9
  • 7
    54801036100 STE.HEAD SCR. M20X1,5 WS=27 SL (SELF-LOCKING)
    STE.HEAD SCR. M20X1,5 WS=27 SL (SELF-LOCKING)
  • 8
    0770025035 O-RING 25X3,55 NBR70
    O-RING 25X3,55 NBR70
  • 9
    0017060204 EJOT PT SCREW K60X20 ALU WS=6
    EJOT PT SCREW K60X20 ALU WS=6
  • 32
    59401031019 BOTTOM TRIPLE CLAMP D=60MM
    BOTTOM TRIPLE CLAMP D=60MM
  • 33
    59401033000 FORK TUBE L=237MM
    FORK TUBE L=237MM
  • 34
    59401034019 TOP TRIPLE CLAMP D=54MM
    TOP TRIPLE CLAMP D=54MM
  • 36
    54801036000 STEER.HEAD SCREW M20X1,5WS=27
    STEER.HEAD SCREW M20X1,5WS=27
  • 38
    59401038000 HANDLEBAR CLAMP 28MM
    HANDLEBAR CLAMP 28MM
  • 39
    59401039032 HANDLEB.SUPP. D=28MM H=32MM
    HANDLEB.SUPP. D=28MM H=32MM
  • 39
    59401039037 HANDLEB.SUPP. D=28MM H=37MM
    HANDLEB.SUPP. D=28MM H=37MM
  • 39
    59401039042 HANDLEB.SUPP. D=28MM H=42MM
    HANDLEB.SUPP. D=28MM H=42MM
  • 81
    54201081000 TAPERED ROLLER BEARING CPL.
    TAPERED ROLLER BEARING CPL.
  • 82
    54601084100 O-RING SUPPORT W. SEALING LIP
    O-RING SUPPORT W. SEALING LIP
  • 84
    54601184000 STEARING HEAD GASKET TOP
    STEARING HEAD GASKET TOP
  • 85
    59001085100 CLAMP F.SPEED.CABLE D=6MM
    CLAMP F.SPEED.CABLE D=6MM
  • 86
    54201086000 STEERING HEAD COVER
    STEERING HEAD COVER
  • 91
    59001092050 SPECIAL SCREW M6X12,5 WS=8
    SPECIAL SCREW M6X12,5 WS=8
  • 92
    5900109400030 FORK PROTECT. US+R/S BLACK
    FORK PROTECT. US+R/S BLACK
  • 94
    6899785 LOCTITE243 BLUE 6CCM
    LOCTITE243 BLUE 6CCM
