ENGINE CASE для Ktm 450 STEVE RAMON - 2005 года выпуска

  • №
    Артикул
    Название
  • 1
    59030000144 ENGINE CASE CPL. WTR.BEAR.
    ENGINE CASE CPL. WTR.BEAR.
  • 2
    51030026100 DOWEL 17 X 14 X 12
    DOWEL 17 X 14 X 12
  • 3
    49030090000 DOWEL 9,8X7X10
    DOWEL 9,8X7X10
  • 4
    59030090000 HANGER FOR VENT HOSE
    HANGER FOR VENT HOSE
  • 5
    0014060153 HH COLLAR SCREW M 6X15 WS=8
    HH COLLAR SCREW M 6X15 WS=8
  • 6
    58030021000 OILDRAIN PLUG W.MAG. M 12X1,5
    OILDRAIN PLUG W.MAG. M 12X1,5
  • 7
    58038022000 CU-SEAL RING DIN7603-12X18X1,5
    CU-SEAL RING DIN7603-12X18X1,5
  • 9
    0908120153 PLUG DIN0908-M12X1,5
    PLUG DIN0908-M12X1,5
  • 10
    59030024000 DOWEL 17 X 19 X 12
    DOWEL 17 X 19 X 12
  • 11
    58038023300 PRESSURE SPRING L=25MM D=1MM
    PRESSURE SPRING L=25MM D=1MM
  • 12
    58038028000 VALVE PISTON D=10MM
    VALVE PISTON D=10MM
  • 17
    59031050100 ENGINE BREATHER TUBE
    ENGINE BREATHER TUBE
  • 18
    59030022100 BLEEDER FLANGE M12X1,5 WS_13
    BLEEDER FLANGE M12X1,5 WS_13
  • 19
    58030080000 LOCATING SCREW M8 L=23
    LOCATING SCREW M8 L=23
  • 20
    58030081000 CU-SEAL RING 8 X 14 X 3
    CU-SEAL RING 8 X 14 X 3
  • 21
    0402025980 NEEDLE ROLLER DIN5402 2,5X9,8
    NEEDLE ROLLER DIN5402 2,5X9,8
  • 22
    59030019000 OIL LEVEL GLASS G 1777 V
    OIL LEVEL GLASS G 1777 V
  • 23
    58030020000 PLUG M 24X3
    PLUG M 24X3
  • 24
    0770191015 O-RING 19,00X3,00 NBR
    O-RING 19,00X3,00 NBR
  • 26
    0402040980 NEEDLE ROL.DIN5402 NRB 4X9,8
    NEEDLE ROL.DIN5402 NRB 4X9,8
  • 29
    0125050003 WASHER DIN0125-A 5,3
    WASHER DIN0125-A 5,3
  • 30
    0985050083 FLAT HEAD SCREW DIN7985-M 5X 8
    FLAT HEAD SCREW DIN7985-M 5X 8
  • 31
    0015060083 HH COLLAR SCREW M 6X8 WS=8
    HH COLLAR SCREW M 6X8 WS=8
  • 33
    59030001090 RET.BRACKET F.BRAKE LEVER HUB
    RET.BRACKET F.BRAKE LEVER HUB
  • 34
    0770120020 O-RING 12,00X2,00 NBR 70
    O-RING 12,00X2,00 NBR 70
  • 35
    59038014000 PLUG M16X1,5
    PLUG M16X1,5
  • 36
    59038015000 OIL SCREEN 11,8X44,5MM
    OIL SCREEN 11,8X44,5MM
  • 37
    0770090015 O-RING 9X1,5 NBR
    O-RING 9X1,5 NBR
  • 38
    0603121830 SEAL RING 1J1N760312X18X3
    SEAL RING 1J1N760312X18X3
  • 41
    59030025100 GASKET FOR CLUTCH COVER
    GASKET FOR CLUTCH COVER
  • 42
    59030039100 ENGINE CASE GASKET NS92-24
    ENGINE CASE GASKET NS92-24
  • 43
    59030001000 CLUTCH COVER RACING
    CLUTCH COVER RACING
  • 44
    59030047000 CHAIN DAMPERSHEET RACING
    CHAIN DAMPERSHEET RACING
  • 50
    0015060453 HH COLLAR SCREW M 6X45 WS=8
    HH COLLAR SCREW M 6X45 WS=8
  • 51
    0015060603 HH COLLAR SCREW M 6X60 WS=8
    HH COLLAR SCREW M 6X60 WS=8
  • 52
    0015060303 HH COLLAR SCREW M 6X30 WS=8
    HH COLLAR SCREW M 6X30 WS=8
  • 53
    0015060353 HH COLLAR SCREW M 6X35 WS=8
    HH COLLAR SCREW M 6X35 WS=8
  • 54
    0015060753 HH COLLAR SCREW M 6X75 WS=8
    HH COLLAR SCREW M 6X75 WS=8
  • 60
    59030099000 GASKET SET CPL. RACING
    GASKET SET CPL. RACING
