FRAME W/ SUB FRAME для Ktm 450 RALLYE - 2005 года выпуска
-
№АртикулНазвание
-
15850300144490 FRAME 660 RALLYE E-STARTFRAME 660 RALLYE E-START
-
30910160153 PLUG DIN0910-M16X1,5PLUG DIN0910-M16X1,5
-
40603162220 CU-SEAL RING 16X22X2CU-SEAL RING 16X22X2
-
758503012100 ENGINE PROT. BRACKET 22ENGINE PROT. BRACKET 22
-
1358303070000 STOP RUBBER M8STOP RUBBER M8
-
170015050123 HH COLLAR SCREW M 5X12 WS=8HH COLLAR SCREW M 5X12 WS=8
-
200934080003 HEXAGON NUT DIN0934-M 8HEXAGON NUT DIN0934-M 8
-
290934080003 HEXAGON NUT DIN0934-M 8HEXAGON NUT DIN0934-M 8
-
320912101603 AH SCREW DIN0912-M10X160AH SCREW DIN0912-M10X160
-
3454630044000 COLLAR NUT M10 WS=13COLLAR NUT M10 WS=13
-
350797100003 LOCK WASHER DIN6797-J10,5 ZILOCK WASHER DIN6797-J10,5 ZI
-
3654435024001 HOSE ID 7,5 PER METERHOSE ID 7,5 PER METER
-
3744011076100 CABLE TIE 100/2,5MM BLACKCABLE TIE 100/2,5MM BLACK
-
380912060203 AH SCREW DIN0912-M 6X20AH SCREW DIN0912-M 6X20
-
4059003040250 FOOT PED L/S SILVERFOOT PED L/S SILVER
-
4059003041250 FOOT PED R/S SILVERFOOT PED R/S SILVER
-
4254603041000 FOOTREST SPRING L/S & R/SFOOTREST SPRING L/S & R/S
-
4454603044000 BOLT FOR FOOTREST 9,8 X 50BOLT FOR FOOTREST 9,8 X 50
-
460125100003 WASHER DIN0125-A10,5WASHER DIN0125-A10,5
-
470094032253 PIN DIN0094-3,2X25 STEELPIN DIN0094-3,2X25 STEEL
-
4954603048000 RANGE CHANGE METAL NUT M8RANGE CHANGE METAL NUT M8
-
5158503002410 TANK HOLDER DOWN L/STANK HOLDER DOWN L/S
-
5258503002430 TANK HOLDER DOWN R/STANK HOLDER DOWN R/S
-
5354804067000 CHAIN SLIDING PIECECHAIN SLIDING PIECE
-
5452303053100 CHAIN ROLL D=35MMCHAIN ROLL D=35MM
-
5574003021000 BUSHING 8.2 X 12 X 6BUSHING 8.2 X 12 X 6
-
560625006087 GROOVED BALL BEAR. 608 2RS C3GROOVED BALL BEAR. 608 2RS C3
-
5754611186000 RUBBER BANDRUBBER BAND
-
5858503023170 SIDE STAND RUBBER-RET.PANEL 01SIDE STAND RUBBER-RET.PANEL 01
-
5951103053051 BUSHING 8,2X10X20BUSHING 8,2X10X20
-
6354305069000 BUSHING 7X12X15,4BUSHING 7X12X15,4
-
640912060203 AH SCREW DIN0912-M 6X20AH SCREW DIN0912-M 6X20
-
6836003014000 LOCK WASHER 8MMLOCK WASHER 8MM
-
700015080353 HH COLLAR SCREW M 8X35 WS=10HH COLLAR SCREW M 8X35 WS=10
-
710015080603 HH COLLAR SCREW M 8X60 WS=10HH COLLAR SCREW M 8X60 WS=10
-
720984060103 AH SCREW DIN7984-M 6X10AH SCREW DIN7984-M 6X10
