SHOCK ABSORBER - DISASSEMBLED для Ktm 65 SX - 2004 года выпуска
-
№АртикулНазвание
-
146811525 SHOCK ABS. BOTTOM L=46SHOCK ABS. BOTTOM L=46
-
236120586 PISTON ROD D=14; L=126PISTON ROD D=14; L=126
-
346811401S NEEDLE CPL. D=4; L=142NEEDLE CPL. D=4; L=142
-
446811222 O-RING 36X0,5O-RING 36X0,5
-
546811263 WASHERWASHER
-
646811261 PIN 4X35PIN 4X35
-
746811262 ADJ. KNOB D=41ADJ. KNOB D=41
-
1046811221 O-RING 35X3O-RING 35X3
-
1146811367 INTERMEDIATO RING H=4INTERMEDIATO RING H=4
-
1246811268 CIRCLIP 22X1,2CIRCLIP 22X1,2
-
1346811259 NEEDLE SEAT 5X17,25NEEDLE SEAT 5X17,25
-
1646811076 ADAPTOR BUSH KGW 10X20ADAPTOR BUSH KGW 10X20
-
1746811027 BUSHING KGW 1525BUSHING KGW 1525
-
1846811077 ADAPTOR BUSH KGW 10X22ADAPTOR BUSH KGW 10X22
-
1946811050 SEAL KGWSEAL KGW
-
2236120135 BUMP RUBBER WP65 REDBUMP RUBBER WP65 RED
-
2336120650 SCREW CAP M37,65 STEELSCREW CAP M37,65 STEEL
-
2446811044 DUST SEAL 1424DUST SEAL 1424
-
2536120064 O-RING NBR 29,74X3,53O-RING NBR 29,74X3,53
-
2636120522S1 ADAPTOR CPL. D=36 H=20,5ADAPTOR CPL. D=36 H=20,5
-
2736120469 WASHER 28,5X14X2WASHER 28,5X14X2
-
3036120726 SHOCK ABSORB.CASE PGB KGW H=33SHOCK ABSORB.CASE PGB KGW H=33
-
3140540037 O-RING 38X2O-RING 38X2
-
3236120137 TUBE L=167TUBE L=167
-
3336120019 THREADED BUSH L=70 BLACKTHREADED BUSH L=70 BLACK
-
3436120467 PROTECTION SLEEVE L=40PROTECTION SLEEVE L=40
-
4136120015 COUNTERNUTCOUNTERNUT
-
4236120418 ADJUSTING NUTADJUSTING NUT
-
4340540015 CIRCLIP 38X1,5CIRCLIP 38X1,5
-
4546810893 O-RING NBR 5,28X1,78O-RING NBR 5,28X1,78
-
4636120151 SCREW PLUG M5X6SCREW PLUG M5X6
-
4793010049 SPRING WP 40-220SPRING WP 40-220
-
4793010050 SPRING WP 45-220SPRING WP 45-220
-
4836120386 SPRING RET H=3; D=14,5SPRING RET H=3; D=14,5
-
4946811208 RUBBER CAP "DO NOT OPEN"RUBBER CAP "DO NOT OPEN"
-
5050180342S1 SHOCK ABSORBER FLUID 5 LTSHOCK ABSORBER FLUID 5 LT
-
6036120557 REBOUND BUSH H=5,6REBOUND BUSH H=5,6
-
6236120312 BACKPLATE 10X16X0,30BACKPLATE 10X16X0,30
-
6236120334 SHIM 10X21X0,20SHIM 10X21X0,20
-
6236120335 SHIM 10X23X0,20SHIM 10X23X0,20
-
6236120336 SHIM 10X25X0,20SHIM 10X25X0,20
-
6236120337 SHIM 10X27X0,20SHIM 10X27X0,20
-
6236120330 SHIM 10X29X0,15SHIM 10X29X0,15
-
6236120331 SHIM 10X31X0,15SHIM 10X31X0,15
-
6236120332 SHIM 10X33X0,15SHIM 10X33X0,15
-
6236120329 SHIM 10X27X0,15SHIM 10X27X0,15
-
6236120325 SHIM 10X19X0,15SHIM 10X19X0,15
-
6236120340 SHIM 10X33X0,20SHIM 10X33X0,20
-
6836120314 BACKPLATE 10X18X0,30BACKPLATE 10X18X0,30
-
6836120342 SHIM 10X21X0,25SHIM 10X21X0,25
-
6836120343 SHIM 10X23X0,25SHIM 10X23X0,25
-
6836120336 SHIM 10X25X0,20SHIM 10X25X0,20
-
6836120284 BACKPLATE 10X16X0,10BACKPLATE 10X16X0,10
-
6836120335 SHIM 10X23X0,20SHIM 10X23X0,20
-
6836120328 SHIM 10X25X0,15SHIM 10X25X0,15
-
7536120603 PISTON 6+6XD=5,5/3,5 BAPISTON 6+6XD=5,5/3,5 BA
-
7736120040 PISTON RING 8X1X108,3PISTON RING 8X1X108,3
-
7846811267 BUSHING 6X9X3BUSHING 6X9X3
-
7946811251 BLEED SCREW M 4X6BLEED SCREW M 4X6
-
8036120604 SHIM D10XD22X2,5SHIM D10XD22X2,5
-
8140540450 SHIM 6X9,5X0,3SHIM 6X9,5X0,3
-
8240540403 SHIM 6X18X0,1SHIM 6X18X0,1
-
8336120605S2 PISTON ROD NUT CPL. H=15,2PISTON ROD NUT CPL. H=15,2
-
8536120631 RESERVOIR SCREW L=98 GREYRESERVOIR SCREW L=98 GREY
-
8636120024 SEPARATION PISTON D=42SEPARATION PISTON D=42
-
8736120466 O-RING VITON 32X5O-RING VITON 32X5
-
8846810022 PISTON RING 3,9X1,5X124PISTON RING 3,9X1,5X124
-
8936120552 SCREW FOR RESERVOIR CAP M5SCREW FOR RESERVOIR CAP M5
-
9046810850S7 CC-COMPRE.DAMPING CONTROL CPL.CC-COMPRE.DAMPING CONTROL CPL.
-
9146810334 LOCK WASHER 1V24LOCK WASHER 1V24
-
9246810333 STEEL-BALL D=4,75STEEL-BALL D=4,75
-
9350180131S ADJUSTING KNOB CC-MECH. CPL.ADJUSTING KNOB CC-MECH. CPL.
-
9450180095 BLEED PLUG R 1/8BLEED PLUG R 1/8
