REAR WHEEL для Ktm 65 SX - 2004 года выпуска

  • №
    Артикул
    Название
  • 1
    46010001144 REARWHEEL-SP 1,6X12 ALU
    REARWHEEL-SP 1,6X12 ALU
  • 2
    46010010144 REAR WHEEL HUB CPL.
    REAR WHEEL HUB CPL.
  • 7
    46010070000 RIM REAR 1,6X12 ALU
    RIM REAR 1,6X12 ALU
  • 8
    46009072100 SPOKE NIPPEL M3,5
    SPOKE NIPPEL M3,5
  • 9
    0625060037 GR.BALL BEAR. 6003-2RSH/C3HMTF
    GR.BALL BEAR. 6003-2RSH/C3HMTF
  • 10
    0625062032 GR.BALL BEAR. 6203-2RSHC3HMTF
    GR.BALL BEAR. 6203-2RSHC3HMTF
  • 12
    59009062013 SPECIAL SCREW M6X13 WS=8 10.9
    SPECIAL SCREW M6X13 WS=8 10.9
  • 13
    46010013000 SPACER BUSH R/S
    SPACER BUSH R/S
  • 14
    46010014000 SPACER BUSH L/S
    SPACER BUSH L/S
  • 15
    46010071100 SPOKE 3X140X4MM-161°.
    SPOKE 3X140X4MM-161°.
  • 16
    46010171100 SPOKE 3X132X5MM-150°.
    SPOKE 3X132X5MM-150°.
  • 17
    0991080253 FLAT HEAD SCREW DIN7991-M 8X25
    FLAT HEAD SCREW DIN7991-M 8X25
  • 18
    54310086200 SELF LOCKING NUT M8 10.9
    SELF LOCKING NUT M8 10.9
  • 19
    46010051046 REAR SPROCKET 46-T
    REAR SPROCKET 46-T
  • 19
    46010051048 REAR SPROCKET 48-T
    REAR SPROCKET 48-T
  • 19
    46010051050 REAR SPROCKET 50-T
    REAR SPROCKET 50-T
  • 22
    46010085100 AXLE REAR 213MM M12X1
    AXLE REAR 213MM M12X1
  • 30
    46110060000 BRAKE DISC REAR
    BRAKE DISC REAR
  • 47
    0125120003 FLAT WASHER DIN0125-A13
    FLAT WASHER DIN0125-A13
  • 49
    0917120103 NUT DIN917-M12X1
    NUT DIN917-M12X1
  • 50
    46110165112 CHAIN 1/2X1/4 WITH M. LINK
    CHAIN 1/2X1/4 WITH M. LINK
  • 51
    46110166000 MASTER LINK 1/2X1/4
    MASTER LINK 1/2X1/4
  • 55
    51009100100 RIM LOCK VM1 (1,60)
    RIM LOCK VM1 (1,60)
  • 56
    50310090050 NUT FOR WHEEL HOLDER
    NUT FOR WHEEL HOLDER
