SHOCK ABSORBER - DISASSEMBLED для Ktm 525 SX RFS - 2004 года выпуска

  • №
    Артикул
    Название
  • 1
    50180350 SHOCK ABSORBER TOP H=30,5 B=21
    SHOCK ABSORBER TOP H=30,5 B=21
  • 2
    50180213S6 DCC-COMPR.DAMP.CONTROL CPL.
    DCC-COMPR.DAMP.CONTROL CPL.
  • 3
    46180007 ADAPTOR BUSH KGW 12X24
    ADAPTOR BUSH KGW 12X24
  • 4
    46180003 OIL SEAL KGW D=25
    OIL SEAL KGW D=25
  • 5
    50180168 WASHER KGW D=25
    WASHER KGW D=25
  • 6
    50180005 BUSHING KGW 1525 HD
    BUSHING KGW 1525 HD
  • 8
    50180095 BLEED PLUG R 1/8
    BLEED PLUG R 1/8
  • 11
    46810016 O-RING NBR 48X2
    O-RING NBR 48X2
  • 12
    52000041 WP CAUTION (PDS KTM) 58X33
    WP CAUTION (PDS KTM) 58X33
  • 13
    50180389 RESERV SCREW L=140 D=52 GOLD
    RESERV SCREW L=140 D=52 GOLD
  • 14
    46180014 O-RING VITON 41X5
    O-RING VITON 41X5
  • 15
    46180002 SEPARATION PISTON D=52; H=32
    SEPARATION PISTON D=52; H=32
  • 16
    46180015 PISTON RING 3,9X1,5X156
    PISTON RING 3,9X1,5X156
  • 18
    50180344 RESERVOIR CAP D=58
    RESERVOIR CAP D=58
  • 19
    46810893 O-RING NBR 5,28X1,78
    O-RING NBR 5,28X1,78
  • 20
    36120151 SCREW PLUG M5X6
    SCREW PLUG M5X6
  • 21
    46811208 RUBBER CAP "DO NOT OPEN"
    RUBBER CAP "DO NOT OPEN"
  • 25
    50180097 O-RING 52X2
    O-RING 52X2
  • 26
    50180177 WASHER 16X8,2X0,6
    WASHER 16X8,2X0,6
  • 27
    50180393 NEEDLE D=10 L=57
    NEEDLE D=10 L=57
  • 27
    50180414 NEEDLE D=7,2 L=57
    NEEDLE D=7,2 L=57
  • 28
    50180271 SCREW CAP M20X1; D=11
    SCREW CAP M20X1; D=11
  • 29
    50180270 LOCK WASHER
    LOCK WASHER
  • 30
    50180295 TUBE PDS L=196
    TUBE PDS L=196
  • 31
    50180133 CIRCLIP 50X1,5
    CIRCLIP 50X1,5
  • 32
    50180081 SPRING GUIDANCE L=40
    SPRING GUIDANCE L=40
  • 35
    50180354 SPRING RETAINER M5
    SPRING RETAINER M5
  • 36
    0912050303 AH SCREW DIN0912-M 5X30
    AH SCREW DIN0912-M 5X30
  • 37
    50180114 INTERM.RING SCREW SPRING RET.
    INTERM.RING SCREW SPRING RET.
  • 40
    91210006 SPRING 250 88N/MM D=13,0 (62)
    SPRING 250 88N/MM D=13,0 (62)
  • 40
    91210002 SPRING 250 72N/MM D=12,5 (59)
    SPRING 250 72N/MM D=12,5 (59)
  • 40
    91210003 SPRING 250 76N/MM D=12,5 (59)
    SPRING 250 76N/MM D=12,5 (59)
  • 40
    91210013 SPRING PDS0-250 65-83N/MM
    SPRING PDS0-250 65-83N/MM
  • 40
    91210009 SPRING PDS1-250 70-90N/MM
    SPRING PDS1-250 70-90N/MM
  • 40
    91210010 SPRING PDS2-250 75-96N/MM
    SPRING PDS2-250 75-96N/MM
  • 40
    91210008 SPRING PDS -250 97N/MM
    SPRING PDS -250 97N/MM
  • 40
    91210011 SPRING PDS3-250 80-103N/MM
    SPRING PDS3-250 80-103N/MM
  • 40
    91210012 SPRING PDS4-250 85-111N/MM
    SPRING PDS4-250 85-111N/MM
  • 40
    91210014 SPRING PDS5-260 66-86N/MM
    SPRING PDS5-260 66-86N/MM
  • 40
    91210015 SPRING PDS6-260 71,5-90,5N/MM
    SPRING PDS6-260 71,5-90,5N/MM
  • 40
    91210016 SPRING PDS7-260 76-95N/MM
    SPRING PDS7-260 76-95N/MM
  • 40
    91210017 SPRING PDS8-260 81-99,5N/MM
    SPRING PDS8-260 81-99,5N/MM
  • 42
    50180273 CIRCLIP 58,2X2
    CIRCLIP 58,2X2
  • 43
    50180355 SPRING RETAINER D=80
    SPRING RETAINER D=80
  • 44
    50180352 O-RING VITON 66,27X3,53
    O-RING VITON 66,27X3,53
  • 45
    50180141 PISTON ROD NUT M16X1
    PISTON ROD NUT M16X1
  • 46
    50180099 O-RING VITON 44,17X1,78
    O-RING VITON 44,17X1,78
  • 47
    50180135 PISTON RING 50-8
    PISTON RING 50-8
  • 48
    50180072 WASHER 16X28X0,30
    WASHER 16X28X0,30
  • 48
    50180209 WASHER 21X36X0,25
    WASHER 21X36X0,25
  • 48
    50180210 WASHER 16X21X1
    WASHER 16X21X1
  • 49
    50180197 PISTON 6+6X7/4,5
    PISTON 6+6X7/4,5
  • 50
    50180035 BACKPLATE 16X21X0,30
    BACKPLATE 16X21X0,30
  • 50
    50180058 WASHER 16X36X0,20
    WASHER 16X36X0,20
  • 50
    50180059 WASHER 16X38X0,20
    WASHER 16X38X0,20
  • 50
    50180060 WASHER 16X40X0,20
    WASHER 16X40X0,20
  • 50
    50180061 WASHER 16X42X0,20
    WASHER 16X42X0,20
  • 50
    50180062 WASHER 16X44X0,20
    WASHER 16X44X0,20
  • 50
    50180063 WASHER 16X28X0,25
    WASHER 16X28X0,25
  • 50
    50180064 WASHER 16X30X0,25
    WASHER 16X30X0,25
  • 50
    50180065 WASHER 16X32X0,25
    WASHER 16X32X0,25
  • 50
    50180066 WASHER 16X34X0,25
    WASHER 16X34X0,25
  • 51
    50180269 SANDWICH BUSH D25XD16X14,5/D
    SANDWICH BUSH D25XD16X14,5/D
  • 54
    50180034 BACKPLATE 16X20X0,30
    BACKPLATE 16X20X0,30
  • 54
    50180045 WASHER 16X28X0,15
    WASHER 16X28X0,15
  • 54
    50180054 WASHER 16X28X0,20
    WASHER 16X28X0,20
  • 54
    50180056 WASHER 16X32X0,20
    WASHER 16X32X0,20
  • 54
    50180057 WASHER 16X34X0,20
    WASHER 16X34X0,20
  • 54
    50180067 WASHER 16X36X0,25
    WASHER 16X36X0,25
  • 56
    50180036 BACKPLATE 16X22X0,30
    BACKPLATE 16X22X0,30
  • 56
    50180048 WASHER 16X34X0,15
    WASHER 16X34X0,15
  • 56
    50180058 WASHER 16X36X0,20
    WASHER 16X36X0,20
  • 56
    50180059 WASHER 16X38X0,20
    WASHER 16X38X0,20
  • 56
    50180060 WASHER 16X40X0,20
    WASHER 16X40X0,20
  • 56
    50180061 WASHER 16X42X0,20
    WASHER 16X42X0,20
  • 56
    50180062 WASHER 16X44X0,20
    WASHER 16X44X0,20
  • 56
    50180064 WASHER 16X30X0,25
    WASHER 16X30X0,25
  • 56
    50180065 WASHER 16X32X0,25
    WASHER 16X32X0,25
  • 56
    50180066 WASHER 16X34X0,25
    WASHER 16X34X0,25
  • 57
    50180322 DISC REBOUND D=34; H=2
    DISC REBOUND D=34; H=2
  • 58
    50180311 PISTON 6+6X7/4,5 VB 1,0
    PISTON 6+6X7/4,5 VB 1,0
  • 60
    50180294 SPINDEL D=18; L=153; M16X1
    SPINDEL D=18; L=153; M16X1
  • 61
    50180200 BUSH M8X1
    BUSH M8X1
  • 62
    50180157 O-RING VITON 7X1,5
    O-RING VITON 7X1,5
  • 63
    50180201 NEEDLE SEAT M8X1
    NEEDLE SEAT M8X1
  • 64
    50180264 TUBE M18X1 L=151,5
    TUBE M18X1 L=151,5
  • 65
    48600049 O-RING NBR 8X2
    O-RING NBR 8X2
  • 66
    50180279 TUBE ADAPTOR M8X1 L=23
    TUBE ADAPTOR M8X1 L=23
  • 70
    50180261 NEEDLE L=175
    NEEDLE L=175
  • 71
    46811265 O-RING VITON 2,2X1,6
    O-RING VITON 2,2X1,6
  • 72
    50180384S ADAPTOR CPL. D=50 H=26,5
    ADAPTOR CPL. D=50 H=26,5
  • 73
    50180314 DISC REBOUND SPRING
    DISC REBOUND SPRING
  • 74
    50180385 REBOUND SPRING
    REBOUND SPRING
  • 75
    50180102 BACKUPRING 22,55X1,5
    BACKUPRING 22,55X1,5
  • 76
    50180101 QUAD RING 18X2,62
    QUAD RING 18X2,62
  • 79
    50180103 O-RING 41X5
    O-RING 41X5
  • 80
    46180119 DU-BUSH 18X20X12
    DU-BUSH 18X20X12
  • 81
    50180082 DUST SEAL 1835
    DUST SEAL 1835
  • 85
    50180126 CIRCLIP 53X1,75
    CIRCLIP 53X1,75
  • 86
    50180165 COVER D=50
    COVER D=50
  • 87
    50180276 BUMP RUBBER WP60 D=18-26
    BUMP RUBBER WP60 D=18-26
  • 88
    50180283 CONTRA NUT M18X1 H=5
    CONTRA NUT M18X1 H=5
  • 89
    48600036 SPACER 42X26,5X2,5
    SPACER 42X26,5X2,5
  • 90
    50180356 FORK PART L=55,5 8=32,5 D=12
    FORK PART L=55,5 8=32,5 D=12
  • 91
    50180105 THREADED BUSH M12 PDS
    THREADED BUSH M12 PDS
  • 92
    50180297 RUBBER PLUG D=8
    RUBBER PLUG D=8
  • 93
    40540603 STEEL BALL D=3MM
    STEEL BALL D=3MM
  • 94
    40540602 SPRING D=2,9; L=6,2
    SPRING D=2,9; L=6,2
  • 95
    50180281 RESERVOIR CAP M14X1
    RESERVOIR CAP M14X1
  • 96
    50180222 O-RING NBR 4X1,5
    O-RING NBR 4X1,5
  • 97
    50180280 ADJUSTING SCREW 80 DEG.; L=39
    ADJUSTING SCREW 80 DEG.; L=39
  • 98
    50180342S1 SHOCK ABSORBER FLUID 5 LT
    SHOCK ABSORBER FLUID 5 LT
  • 99
    R12008 REPAIR-KIT GASKET 5018 PDS
    REPAIR-KIT GASKET 5018 PDS
