GEAR CHANGE MECHANISM для Kawasaki Concours - 2005 года выпуска

  • №
    Артикул
    Название
  • 130
    130S0620 BOLT, FLANGED, 6X20 (BLACK)
    BOLT, FLANGED, 6X20 (BLACK)
  • 132
    132J0660 BOLT, FLANGED, SMALL
    BOLT, FLANGED, SMALL
  • 132A
    132J0670 BOLT, FLANGED, SMALL
    BOLT, FLANGED, SMALL
  • 172
    172G0614 BOLT, STUD, 6X14
    BOLT, STUD, 6X14
  • 311
    311G0600 NUT, HEX, 6MM
    NUT, HEX, 6MM
  • 480
    480J1300 CIRCLIP, TYPE, C, 13MM
    CIRCLIP, TYPE, C, 13MM
  • 13161
    13161-1123 LEVER, COMP, CHANGE SHAFT
    LEVER, COMP, CHANGE SHAFT
  • 13165
    13165-1120 PAWL
    PAWL
  • 13169
    13169-1663 PLATE, CHANGE PEDAL
    PLATE, CHANGE PEDAL
  • 13236
    13236-1103 LEVER, COMP, GEAR POSITION
    LEVER, COMP, GEAR POSITION
  • 13242
    13242-1195 LEVER, ASSY., CHANGE
    LEVER, ASSY., CHANGE
  • 13242A
    13242-1213 LEVER, ASSY., CHANGE, PEDAL
    LEVER, ASSY., CHANGE, PEDAL
  • 39110
    39110-1071 ROD, ASSY., TIE, CHANGE PEDAL
    ROD, ASSY., TIE, CHANGE PEDAL
  • 49006
    49006-1061 BOOT, CHANGE LEVER
    BOOT, CHANGE LEVER
  • 92002
    92002-1816 BOLT
    BOLT
  • 92022
    92022-1593 WASHER, 12.5X22X1.2
    WASHER, 12.5X22X1.2
  • 92026
    92026-094 SPACER, 6.3X12X1.0
    SPACER, 6.3X12X1.0
  • 92026A
    92026-1217 SPACER
    SPACER
  • 92026B
    92026-1532 SPACER, 13.3X18X1.0
    SPACER, 13.3X18X1.0
  • 92033
    92033-1178 RING, SNAP, TYPE, E, 10MM
    RING, SNAP, TYPE, E, 10MM
  • 92075
    92075-1175 DAMPER, CHANGE PEDAL
    DAMPER, CHANGE PEDAL
  • 92081
    92081-1645 SPRING
    SPRING
  • 92081A
    92081-1742 SPRING
    SPRING
  • 92081B
    92081-1750 SPRING, CHANGE PEDAL RETURN
    SPRING, CHANGE PEDAL RETURN
  • 92081C
    92081-1829 SPRING, CHANGE LEVER
    SPRING, CHANGE LEVER
  • 92150
    92150-1869 BOLT, RETURN SPRING
    BOLT, RETURN SPRING
