CABLES для Kawasaki Prairie 360 4x4 (KVF360-A1) - 2003 года выпуска
-
№АртикулНазвание
-
482482L8000 CIRCLIP-TYPE-E, 8MMCIRCLIP-TYPE-E, 8MM
-
5400554005-1203 CABLE-BRAKE, REARCABLE-BRAKE, REAR
-
54005A54005-1211 CABLE-BRAKE, PARKINGCABLE-BRAKE, PARKING
-
5401054010-7501 CABLE, SEAT HOOKCABLE, SEAT HOOK
-
54010A54010-7502 CABLE, FRONT DIFF LOCKCABLE, FRONT DIFF LOCK
-
5401254012-7503 CABLE-THROTTLECABLE-THROTTLE
-
5401754017-7501 CABLE-STARTERCABLE-STARTER
-
9203792037-1092 CLAMP, AIR VENT TUBECLAMP, AIR VENT TUBE
-
9207192071-1058 GROMMET, SENSOR LEADGROMMET, SENSOR LEAD
-
9207292072-030 BAND, L=123BAND, L=123
-
92072A92072-031 BAND, L=149BAND, L=149
-
92072B92072-056 BAND, L=186BAND, L=186
-
92072C92072-1239 BAND, L=188BAND, L=188
Все узлы модели:
- AIR CLEANER
- BATTERY (OPTIONAL) (CANADA ONLY)
- BRAKE - FRONT
- BRAKE - MASTER CYLINDER - FRONT
- BRAKE PEDAL
- • CABLES
- CAMSHAFT(S)/TENSIONER
- CARBURETOR
- CARRIER(S)
- CHASSIS ELECTRICAL EQUIPMENT
- CONTROL
- CONVERTER COVER/DRIVE BELT
- CRANKCASE
- CRANKSHAFT
- CYLINDER HEAD
- CYLINDER/PISTON(S)
- DECALS (GREEN)
- DECALS (RED)
- DRIVE CONVERTER
- DRIVE SHAFT- PROPELLER
- DRIVE SHAFT- REAR
- DRIVE SHAFT-FRONT (-JKBVFHA1 4B531603)
- DRIVEN CONVERTER
- ENGINE COVER(S)
- ENGINE MOUNT
- FENDER - FRONT
- FENDER - REAR
- FOOTRESTS
- FRAME
- FRAME FITTINGS
- FRONT BEVEL GEAR
- FRONT HUB
- FUEL TANK
- GEAR CHANGE MECHANISM
- GENERATOR
- GUARD(S)
- HANDLEBAR
- HEADLIGHT(S)
- IGNITION SWITCH
- IGNITION SYSTEM
- LABELS
- METER(S) (CANADA ONLY)
- MUFFLER(S)
- OIL COOLER
- OIL PUMP/OIL FILTER
- OPTIONAL PARTS (CONVERTER)
- OPTIONAL PARTS (METER(S) (US ONLY)
- OWNER'S TOOLS
- PUBLICATIONS
- REAR HUB
- REFLECTORS (CANADA ONLY)
- SEAT
- SIDE COVERS
- STARTER - RECOIL
- STARTER MOTOR
- SUSPENSION
- SUSPENSION - SHOCK ABSORBER
- SUSPENSION - SWINGARM
- TAILLIGHT(S) (JKBVFHA1 3B524151 AND ABOVE)
- TAILLIGHT(S) (UP TO JKBVFHA1 3B524150)
- TRANSMISSION
- VALVE(S)
- WHEELS/TIRES
