05- Drive System 2 для BRP Ski-Doo Elite 1500 1st Edition - 2004
-
№АртикулНазвание
-
1504152285 Gear 38 TeethGear 38 Teeth
-
2512059991 WasherWasher
-
3506150000 Washer 10 mmWasher 10 mm
-
4245004060 Hex Screw M10 X 40 (Scotch Grip)Hex Screw M10 X 40 (Scotch Grip)
-
5293800070 Loctite 767, Antiseize Lubricant, 8 OzLoctite 767, Antiseize Lubricant, 8 Oz
-
6504151750 Filler Cap Ass'YFiller Cap Ass'Y
-
7414969400 O-RingO-Ring
-
8413803300 Synthetic Chaincase Oil, 12 X 355 mlSynthetic Chaincase Oil, 12 X 355 ml
-
9504152166 Transmission SupportTransmission Support
-
10210282540 Hex Forming Screw M8 X 25Hex Forming Screw M8 X 25
-
11250000118 Hex Screw With NylonHex Screw With Nylon
-
12503183200 Washer (Yellow)Washer (Yellow)
-
13504152227 Rear ExtrusionRear Extrusion
-
14518323288 Fixation PlateFixation Plate
-
15390402200 Pop Rivet 3/16''Pop Rivet 3/16''
-
16504152228 Front ExtrusionFront Extrusion
-
17233281414 Elastic Flanged Nut M8Elastic Flanged Nut M8
-
18504152229 Battery SupportBattery Support
-
19278001582 Lower Battery PadLower Battery Pad
-
20504152350 Battery AttachBattery Attach
-
21504152351 Anchor RodAnchor Rod
-
22232561414 Elastic Stop Nut M6Elastic Stop Nut M6
-
23234062410 Flat Washer 6 mmFlat Washer 6 mm
-
24207682044 Hex Flanged Screw M8 X 20Hex Flanged Screw M8 X 20
-
25233281414 Elastic Flanged Nut M8Elastic Flanged Nut M8
-
26230102044 Hex Screw M10 X 12Hex Screw M10 X 12
-
27232006414 Hex Nut M10Hex Nut M10
-
28504152230 PivotPivot
-
29504152243 Pivot PlatePivot Plate
-
30504152242 Shifting RodShifting Rod
-
31504152281 SpringSpring
-
32207662544 Hex Flanged Screw M6 X 25Hex Flanged Screw M6 X 25
-
33233261414 Elastic Flanged Nut M6Elastic Flanged Nut M6
-
34520000234 CushionCushion
-
35504152332 Tightening BushingTightening Bushing
-
36207663544 Hex Flanged Screw M6 X 35Hex Flanged Screw M6 X 35
-
37506151729 LH Ball JointLH Ball Joint
-
38219700417 Synthetic Grease, 400gSynthetic Grease, 400g
-
39232180600 Hex Jam Nut M8Hex Jam Nut M8
-
40504152330 Ball Joint SupportBall Joint Support
-
41505070817 Sliding BlockSliding Block
-
42505070819 Ball JointBall Joint
-
43504152154 LeverLever
-
44705500022 Lever ButtonLever Button
-
45250000172 Socket Head Screw M6 X 16Socket Head Screw M6 X 16
-
46415107300 InsertInsert
-
47210251180 Hex. Forming Screw M5 x 11Hex. Forming Screw M5 x 11
-
48207663544 Hex Flanged Screw M6 X 35Hex Flanged Screw M6 X 35
-
49233261414 Elastic Flanged Nut M6Elastic Flanged Nut M6
