REAR SUSPENSION REAR ARM ASSEMBLY для Arctic Cat ZR 9000 RR 137 GREEN - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    2704-389 ARM, REAR - BLACK (INC. ONE NO. 2)
    ARM, REAR - BLACK (INC. ONE NO. 2)
  • 2
    1623-010 ...FITTING, GREASE
    ...FITTING, GREASE
  • 3
    3604-965 AXLE
    AXLE
  • 4
    8413-031 SCREW, CAP
    SCREW, CAP
  • 5
    8413-041 SCREW, CAP
    SCREW, CAP
  • 6
    2704-002 ARM, IDLER - BLACK (INC. 7 AND ONE NO. 2)
    ARM, IDLER - BLACK (INC. 7 AND ONE NO. 2)
  • 7
    1604-100 ...BUSHING, FLARED
    ...BUSHING, FLARED
  • 8
    3604-276 AXLE
    AXLE
  • 9
    1604-204 BLOCK, SPRING ADJUSTER - RIGHT - BLACK
    BLOCK, SPRING ADJUSTER - RIGHT - BLACK
  • 9
    1604-205 BLOCK, SPRING ADJUSTER - LEFT - BLACK
    BLOCK, SPRING ADJUSTER - LEFT - BLACK
  • 10
    0623-138 RING, RETAINING
    RING, RETAINING
  • 11
    3604-288 SLEEVE, SPRING
    SLEEVE, SPRING
  • 12
    2704-026 SPRING, SUSPENSION - RIGHT
    SPRING, SUSPENSION - RIGHT
  • 12
    2704-027 SPRING, SUSPENSION - LEFT
    SPRING, SUSPENSION - LEFT
  • 13
    3604-901 WHEEL, IDLER (INC. 14-15)
    WHEEL, IDLER (INC. 14-15)
  • 14
    3604-257 ...BEARING
    ...BEARING
  • 15
    3604-256 ...RING, RETAINING
    ...RING, RETAINING
  • 16
    3604-674 SPACER, PIVOT - IDLER ARM
    SPACER, PIVOT - IDLER ARM
  • 17
    3604-979 AXLE
    AXLE
  • 18
    3604-930 WASHER
    WASHER
  • 19
    3704-007 PIVOT - IDLER ARM (INC. 20-22)
    PIVOT - IDLER ARM (INC. 20-22)
  • 20
    8427-802 ...NUT
    ...NUT
  • 21
    8408-860 ...SCREW, CAP
    ...SCREW, CAP
  • 22
    3604-713 ...BUSHING, FLARED
    ...BUSHING, FLARED
  • 23
    2623-002 SCREW, CAP
    SCREW, CAP
  • 24
    8408-090 SCREW, CAP
    SCREW, CAP
  • 25
    3604-330 AXLE, LINK
    AXLE, LINK
  • 26
    0704-928 LINK, SHOCK
    LINK, SHOCK
  • 27
    3604-109 SLEEVE
    SLEEVE
  • 28
    2623-076 NUT, LOCK W/WASHER
    NUT, LOCK W/WASHER
  • 29
    8408-045 SCREW, CAP
    SCREW, CAP
