STEERING POST ASSEMBLY для Arctic Cat ZR 6000 R SX GREEN [S2016ACDPRUSG] - 2016 года выпуска
-
№АртикулНазвание
-
18408-830 SCREW, CAPSCREW, CAP
-
21605-118 CAP, STEERINGCAP, STEERING
-
31605-112 BLOCK, RISER - 3.5 IN.BLOCK, RISER - 3.5 IN.
-
31605-086 BLOCK, RISER - 2.0 IN. (OPTIONAL)BLOCK, RISER - 2.0 IN. (OPTIONAL)
-
31605-063 BLOCK, RISER - 3.0 IN. (OPTIONAL)BLOCK, RISER - 3.0 IN. (OPTIONAL)
-
31605-035 BLOCK, RISER - 4.5 IN. (OPTIONAL)BLOCK, RISER - 4.5 IN. (OPTIONAL)
-
31605-073 BLOCK, RISER (OPTIONAL)BLOCK, RISER (OPTIONAL)
-
31605-034 BLOCK, RISER - 6.5 IN. (OPTIONAL)BLOCK, RISER - 6.5 IN. (OPTIONAL)
-
31605-070 BLOCK, RISER - 7.5 IN. (OPTIONAL)BLOCK, RISER - 7.5 IN. (OPTIONAL)
-
31605-071 BLOCK, RISER - 8.5 IN. (OPTIONAL)BLOCK, RISER - 8.5 IN. (OPTIONAL)
-
48408-800 SCREW, CAPSCREW, CAP
-
50605-722 PLATE, RETAININGPLATE, RETAINING
-
60605-576 BLOCK, MOUNTING - STEERING POSTBLOCK, MOUNTING - STEERING POST
-
71605-092 STAND-OFF, MOUNTING BLOCK - 26 MMSTAND-OFF, MOUNTING BLOCK - 26 MM
-
71605-095 STAND-OFF, MOUNTING BLOCK - 13 MM (OPTIONAL)STAND-OFF, MOUNTING BLOCK - 13 MM (OPTIONAL)
-
71605-096 STAND-OFF, MOUNTING BLOCK - 39 MM (OPTIONAL)STAND-OFF, MOUNTING BLOCK - 39 MM (OPTIONAL)
-
88427-802 NUT, LOCKNUT, LOCK
-
91705-459 POST, STEERINGPOST, STEERING
-
101605-089 SPACERSPACER
-
118427-002 NUT, LOCKNUT, LOCK
