SKID PLATE AND SIDE PANEL ASSEMBLY для Arctic Cat ZR 8000 SNO PRO RR (GREEN) [S2015ZRHRRUSG] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    4718-214 PANEL, SIDE W/DECALS - RIGHT - (BLACK) (INC. 2-11)
    PANEL, SIDE W/DECALS - RIGHT - (BLACK) (INC. 2-11)
  • 2
    3718-180 ...PANEL, SIDE W/FOAM - RIGHT - (BLACK) (INC. 3-7)
    ...PANEL, SIDE W/FOAM - RIGHT - (BLACK) (INC. 3-7)
  • 3
    0617-626 ......FOAM, SIDE PANEL - UPPER FRONT - RIGHT
    ......FOAM, SIDE PANEL - UPPER FRONT - RIGHT
  • 4
    6606-414 ......FOIL, PROTECTIVE-MIDDLE SIDE PANEL-RIGHT
    ......FOIL, PROTECTIVE-MIDDLE SIDE PANEL-RIGHT
  • 5
    0617-628 ......FOAM, SIDE PANEL - UPPER REAR - RIGHT
    ......FOAM, SIDE PANEL - UPPER REAR - RIGHT
  • 6
    0617-632 ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT
    ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT
  • 7
    0617-634 ......FOAM, SIDE PANEL - LOWER REAR - RIGHT
    ......FOAM, SIDE PANEL - LOWER REAR - RIGHT
  • 8
    1621-354 ...DECAL, SIDE PANEL - UPPER - RIGHT
    ...DECAL, SIDE PANEL - UPPER - RIGHT
  • 9
    1621-356 ...DECAL, SIDE PANEL - LOWER - RIGHT
    ...DECAL, SIDE PANEL - LOWER - RIGHT
  • 10
    1621-360 ...DECAL, SIDE PANEL - CENTER - RIGHT
    ...DECAL, SIDE PANEL - CENTER - RIGHT
  • 11
    1621-358 ...DECAL, SIDE PANEL - FORWARD - RIGHT
    ...DECAL, SIDE PANEL - FORWARD - RIGHT
  • 12
    4718-581 PANEL, SIDE W/DECALS - LEFT - (BLACK) (INC. 13-21)
    PANEL, SIDE W/DECALS - LEFT - (BLACK) (INC. 13-21)
  • 13
    4718-553 ...PANEL, SIDE W/FOAM - LEFT - (BLACK) (INC. 14-16)
    ...PANEL, SIDE W/FOAM - LEFT - (BLACK) (INC. 14-16)
  • 14
    0617-629 ......FOAM, SIDE PANEL - UPPER REAR - LEFT
    ......FOAM, SIDE PANEL - UPPER REAR - LEFT
  • 15
    0617-635 ......FOAM, SIDE PANEL - LOWER REAR - LEFT
    ......FOAM, SIDE PANEL - LOWER REAR - LEFT
  • 16
    0617-681 ......FOAM, SIDE PANEL - LOWER FRONT - LEFT
    ......FOAM, SIDE PANEL - LOWER FRONT - LEFT
  • 17
    2621-301 ...DECAL, SIDE PANEL - UPPER - LEFT
    ...DECAL, SIDE PANEL - UPPER - LEFT
  • 18
    1621-357 ...DECAL, SIDE PANEL - LOWER - LEFT
    ...DECAL, SIDE PANEL - LOWER - LEFT
  • 19
    2621-299 ...DECAL, SIDE PANEL - CENTER - LEFT
    ...DECAL, SIDE PANEL - CENTER - LEFT
  • 20
    1621-359 ...DECAL, SIDE PANEL - FORWARD - LEFT
    ...DECAL, SIDE PANEL - FORWARD - LEFT
  • 21
    2621-297 ...DECAL, SIDE PANEL - MID VENT - LEFT
    ...DECAL, SIDE PANEL - MID VENT - LEFT
  • 22
    1623-637 CLIP, U-NUT
    CLIP, U-NUT
  • 23
    0607-447 CABLE - (5 IN.)
    CABLE - (5 IN.)
  • 24
    0605-283 CLIP, HAIRPIN
    CLIP, HAIRPIN
  • 25
    8060-486 RIVET
    RIVET
  • 26
    8050-127 WASHER
    WASHER
  • 27
    1623-052 CLIP, U-NUT
    CLIP, U-NUT
  • 28
    6606-925 SCREEN, INTAKE
    SCREEN, INTAKE
  • 29
    2602-794 DUCT, INTAKE - INNER
    DUCT, INTAKE - INNER
  • 30
    1623-030 CLIP, U-NUT
    CLIP, U-NUT
  • 31
    2602-793 DUCT, INTAKE - OUTER - (BLACK)
    DUCT, INTAKE - OUTER - (BLACK)
  • 32
    1702-369 DUCT, AIR - CLUTCH
    DUCT, AIR - CLUTCH
  • 33
    6606-694 FOIL, PROTECTIVE
    FOIL, PROTECTIVE
  • 34
    0623-797 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 35
    4718-218 PLATE, SKID W/DECALS - RIGHT - (TEAM ARCTIC GREEN) (INC. 36-44)
    PLATE, SKID W/DECALS - RIGHT - (TEAM ARCTIC GREEN) (INC. 36-44)
  • 36
    4718-220 ...PLATE, SKID W/FOAM - RIGHT - (TEAM ARCTIC GREEN) (INC. 37-43)
    ...PLATE, SKID W/FOAM - RIGHT - (TEAM ARCTIC GREEN) (INC. 37-43)
  • 37
    0617-640 ......FOAM, SKID PLATE - UPPER REAR - RIGHT
    ......FOAM, SKID PLATE - UPPER REAR - RIGHT
  • 38
    0617-638 ......FOAM, SKID PLATE - CENTER FRONT - RIGHT
    ......FOAM, SKID PLATE - CENTER FRONT - RIGHT
  • 39
    0617-636 ......FOAM, SKID PLATE - UPPER FRONT - RIGHT
    ......FOAM, SKID PLATE - UPPER FRONT - RIGHT
  • 40
    2612-850 ......FOIL, PROTECTIVE-RESONATOR
    ......FOIL, PROTECTIVE-RESONATOR
  • 41
    8061-708 ......RIVET
    ......RIVET
  • 42
    2612-754 ......DEFLECTOR, HEAT
    ......DEFLECTOR, HEAT
  • 43
    0123-802 ......WASHER
    ......WASHER
  • 44
    1621-362 ...DECAL, SKID PLATE -REAR RIGHT
    ...DECAL, SKID PLATE -REAR RIGHT
  • 45
    4718-219 PLATE, SKID W/DECALS - LEFT - (TEAM ARCTIC GREEN) (INC. 46-51)
    PLATE, SKID W/DECALS - LEFT - (TEAM ARCTIC GREEN) (INC. 46-51)
  • 46
    4718-221 ...PLATE, SKID W/FOAM - LEFT - (TEAM ARCTIC GREEN) (INC. 47-50)
    ...PLATE, SKID W/FOAM - LEFT - (TEAM ARCTIC GREEN) (INC. 47-50)
  • 47
    0617-637 ......FOAM, SKID PLATE - UPPER FRONT - LEFT
    ......FOAM, SKID PLATE - UPPER FRONT - LEFT
  • 48
    0617-639 ......FOAM, SKID PLATE - CENTER FRONT - LEFT
    ......FOAM, SKID PLATE - CENTER FRONT - LEFT
  • 49
    0617-641 ......FOAM, SKID PLATE - UPPER REAR - LEFT
    ......FOAM, SKID PLATE - UPPER REAR - LEFT
  • 50
    6606-613 ......PANEL, REINFORCEMENT
    ......PANEL, REINFORCEMENT
  • 51
    1621-363 ...DECAL, SKID PLATE - LEFT
    ...DECAL, SKID PLATE - LEFT
  • 52
    2623-005 CLIP, RETAINING
    CLIP, RETAINING
  • 53
    6606-592 PIN, RETAINING
    PIN, RETAINING
  • 54
    1623-129 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 55
    2612-796 PLATE, EXHAUST OUTLET
    PLATE, EXHAUST OUTLET
  • 56
    2612-795 SEAL, EXHAUST OUTLET
    SEAL, EXHAUST OUTLET
  • 57
    8061-710 RIVET, BLIND
    RIVET, BLIND
  • 58
    6606-295 SHIELD, HEAT - ECM
    SHIELD, HEAT - ECM
  • 59
    8408-620 SCREW, CAP
    SCREW, CAP
  • 60
    0423-031 CLIP, U-NUT
    CLIP, U-NUT
  • 61
    0623-784 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 62
    6606-342 FASCIA, FRONT - RIGHT - (BLACK)
    FASCIA, FRONT - RIGHT - (BLACK)
  • 62
    3718-303 FASCIA, FRONT - LEFT - (BLACK) (INC. 63)
    FASCIA, FRONT - LEFT - (BLACK) (INC. 63)
  • 63
    6606-405 ...FOIL, PROTECTIVE
    ...FOIL, PROTECTIVE
  • 64
    2623-001 NUT, PUSH (OPTIONAL)
    NUT, PUSH (OPTIONAL)
  • 65
    1623-999 SCREW, THUMB (OPTIONAL)
    SCREW, THUMB (OPTIONAL)
