STEERING POST ASSEMBLY для Arctic Cat ZR 8000 LXR (GREEN) [S2015ZRHLXUSG] - 2015 года выпуска
-
№АртикулНазвание
-
18408-830 SCREW, CAPSCREW, CAP
-
21605-118 CAP, STEERINGCAP, STEERING
-
31605-073 BLOCK, RISER - (5.5 IN.)BLOCK, RISER - (5.5 IN.)
-
48427-602 NUT, LOCKNUT, LOCK
-
50605-998 PLATE, RETAININGPLATE, RETAINING
-
61605-043 BLOCK, MOUNTING - STEERING POST - UPPERBLOCK, MOUNTING - STEERING POST - UPPER
-
71605-044 BLOCK, MOUNTING - STEERING POST - LOWERBLOCK, MOUNTING - STEERING POST - LOWER
-
82623-079 SCREW, MACHINESCREW, MACHINE
-
91705-309 POST, STEERING - (BLACK)POST, STEERING - (BLACK)
-
102623-076 WASHER, INTERNAL TOOTH LOCKWASHER, INTERNAL TOOTH LOCK
