FRONT BUMPER AND FRAME ASSEMBLY для Arctic Cat ZR 5000 LXR EARLY BUILD (GREEN) [S2015ZRNLXUSG] - 2015 года выпуска
-
№АртикулНазвание
-
12707-475 PANEL,FRT-ASSY (10MM) 5000/8000-PTD (BLACK) (INC. 2-6)PANEL,FRT-ASSY (10MM) 5000/8000-PTD (BLACK) (INC. 2-6)
-
20423-577 ...CLIP, U-NUT...CLIP, U-NUT
-
31623-683 ...SCREW, SELF-TAPPING...SCREW, SELF-TAPPING
-
42612-707 ...TAB, SPRING...TAB, SPRING
-
50423-538 ...SCREW, SELF-TAPPING...SCREW, SELF-TAPPING
-
61707-668 ...BRACKET, SHOCK MOUNT - UPPER RIGHT - (BLACK)...BRACKET, SHOCK MOUNT - UPPER RIGHT - (BLACK)
-
61707-669 ...BRACKET, SHOCK MOUNT - UPPER LEFT - (BLACK)...BRACKET, SHOCK MOUNT - UPPER LEFT - (BLACK)
-
78413-617 SCREW, CAPSCREW, CAP
-
81607-233 BRACKET, MOUNTING - UPPER A-ARMBRACKET, MOUNTING - UPPER A-ARM
-
98060-706 ...........................RIVET...........................RIVET
-
102707-496 KIT,STEERING MTGKIT,STEERING MTG
-
110607-991 BRACKET, STEERING STOPBRACKET, STEERING STOP
-
120706-371 TRIM - (3 FT)TRIM - (3 FT)
-
131607-561 GUSSET, A-ARM MOUNTING BRACKET - UPPERGUSSET, A-ARM MOUNTING BRACKET - UPPER
-
141623-241 RIVETRIVET
-
158477-620 SCREW, MACHINESCREW, MACHINE
-
160630-288 REGULATOR, VOLTAGEREGULATOR, VOLTAGE
-
178427-602 NUT, LOCKNUT, LOCK
-
181623-959 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
191605-028 BOOT, STEERING - RIGHTBOOT, STEERING - RIGHT
-
191605-029 BOOT, STEERING - LEFTBOOT, STEERING - LEFT
-
200623-362 CLIP, RETAININGCLIP, RETAINING
-
211707-843 FRAME, LOWER - 4-STROKE - WELDMENTFRAME, LOWER - 4-STROKE - WELDMENT
-
221623-797 INSERTINSERT
-
238427-802 NUT, LOCKNUT, LOCK
-
241623-817 SCREW, SHOULDERSCREW, SHOULDER
-
258468-620 SCREW, MACHINESCREW, MACHINE
-
268060-686 RIVETRIVET
-
270607-983 BELLY PAN - CENTERBELLY PAN - CENTER
-
288476-520 SCREW, MACHINESCREW, MACHINE
-
291607-108 COVER, ACCESS - OIL DRAINCOVER, ACCESS - OIL DRAIN
-
301623-052 CLIP, U-NUTCLIP, U-NUT
-
310623-797 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
321607-063 PANEL, ACCESSPANEL, ACCESS
-
336606-614 BELLY PAN - FRONTBELLY PAN - FRONT
-
341623-929 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
351623-129 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
361707-596 BUMPER, FRONT - ASSEMBLY - BLACK (INC. EIGHT NO. 9 AND 37-38)BUMPER, FRONT - ASSEMBLY - BLACK (INC. EIGHT NO. 9 AND 37-38)
-
371707-576 ...BRACKET, MOUNTING - BUMPER - RIGHT - (BLACK)...BRACKET, MOUNTING - BUMPER - RIGHT - (BLACK)
-
371707-577 ...BRACKET, MOUNTING - BUMPER - LEFT - (BLACK)...BRACKET, MOUNTING - BUMPER - LEFT - (BLACK)
-
381707-578 ....BUMPER, FRONT - (BLACK)....BUMPER, FRONT - (BLACK)
-
390423-609 SCREW, MACHINESCREW, MACHINE
