IDLER WHEEL ASSEMBLY для Arctic Cat PANTERA 7000 LTD (BLACK) [S2015PTULXUSB] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    1604-952 CAP, IDLER WHEEL
    CAP, IDLER WHEEL
  • 2
    8413-675 SCREW,CAP-HFH M6X1.0X75 CL10.9 (SILVER)
    SCREW,CAP-HFH M6X1.0X75 CL10.9 (SILVER)
  • 3
    2623-025 WASHER,STEPPED-6MM ID X 26MM OD-MZ & B
    WASHER,STEPPED-6MM ID X 26MM OD-MZ & B
  • 4
    3604-386 WHEEL, IDLER - ((BLACK)) (INC. 5-6)
    WHEEL, IDLER - ((BLACK)) (INC. 5-6)
  • 5
    3604-033 ......BEARING,WHL-NSK CHINA 6004-W/ENS GREASE
    ......BEARING,WHL-NSK CHINA 6004-W/ENS GREASE
  • 6
    0623-946 ......RING,INTERNAL RETAINING-#165
    ......RING,INTERNAL RETAINING-#165
  • 7
    1423-064 BOLT, HFH M10-1.25X250 CL10.9 RIE (SILVER)
    BOLT, HFH M10-1.25X250 CL10.9 RIE (SILVER)
  • 8
    8422-602 NUT,HEX-THK NYL M6X1.00 CL8 Z & Y
    NUT,HEX-THK NYL M6X1.00 CL8 Z & Y
  • 9
    3604-899 BLOCK, MOUNTING - IDLER WHEEL
    BLOCK, MOUNTING - IDLER WHEEL
  • 10
    8413-620 SCREW,CAP-HFH M6X1.0X20 CL10.9 (SILVER)
    SCREW,CAP-HFH M6X1.0X20 CL10.9 (SILVER)
  • 11
    8427-602 NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & Y
    NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & Y
  • 12
    3604-083 SPACER,FRONT ARM SHOCK
    SPACER,FRONT ARM SHOCK
  • 13
    0623-912 WASHER, FLAT - 0.890 X 1.19 X 0.060 Z & Y
    WASHER, FLAT - 0.890 X 1.19 X 0.060 Z & Y
  • 14
    3604-269 AXLE
    AXLE
  • 15
    1623-992 WASHER, INTERNAL TOOTH LOCK
    WASHER, INTERNAL TOOTH LOCK
  • 16
    8422-002 NUT,HEX-THK NYL M10X1.25 CL8 Z & Y
    NUT,HEX-THK NYL M10X1.25 CL8 Z & Y
  • 17
    3604-039 WHEEL, IDLER (INC. 5-6)
    WHEEL, IDLER (INC. 5-6)
  • 18
    8427-802 NUT,HEX FLG-NYL LOCK M8X1.25 CL8 Z & Y
    NUT,HEX FLG-NYL LOCK M8X1.25 CL8 Z & Y
  • 19
    3604-285 AXLE
    AXLE
  • 20
    3604-325 SPACER, AUX WHEEL-INSIDE
    SPACER, AUX WHEEL-INSIDE
  • 21
    1704-674 PIVOT, SHOCK (INC. 22)
    PIVOT, SHOCK (INC. 22)
  • 22
    1623-010 ...FITTING,GREASE-1/4-28 UNF-SELF THREAD
    ...FITTING,GREASE-1/4-28 UNF-SELF THREAD
  • 23
    1623-794 WASHER,FLAT-.631 X 1.000 X .063 Z & Y
    WASHER,FLAT-.631 X 1.000 X .063 Z & Y
  • 24
    3604-327 BLOCK, MOUNTING - IDLER WHEEL
    BLOCK, MOUNTING - IDLER WHEEL
  • 25
    1704-279 SPRING, TRIPLE OVERLOAD ASSY-SLOTTED (INC. 26-29)
    SPRING, TRIPLE OVERLOAD ASSY-SLOTTED (INC. 26-29)
  • 26
    2604-788 ...BLOCK,WEAR-SPRING SLIDE - .19 HOLE
    ...BLOCK,WEAR-SPRING SLIDE - .19 HOLE
  • 27
    0623-121 ...SCREW,MACH-PHTRH #10-32X3/4 Z & Y
    ...SCREW,MACH-PHTRH #10-32X3/4 Z & Y
  • 28
    8041-276 ...NUT,HEX THIN LOCK-NYL 10-32 Z & Y
    ...NUT,HEX THIN LOCK-NYL 10-32 Z & Y
  • 29
    1604-412 ...CLIP,RETAINING H.D.-SLOTTED
    ...CLIP,RETAINING H.D.-SLOTTED
  • 30
    0623-746 WASHER,2.00X.386X.1046
    WASHER,2.00X.386X.1046
  • 31
    0604-739 BUSHING, OVERLOAD SPRING
    BUSHING, OVERLOAD SPRING
  • 32
    1604-430 SPACER, SPRING SLIDE
    SPACER, SPRING SLIDE
  • 33
    2604-516 SLIDE, SPRING-TALL
    SLIDE, SPRING-TALL
  • 34
    8450-133 WASHER,FLAT-M8-9.12 X 25.40 X 2.30Z & Y
    WASHER,FLAT-M8-9.12 X 25.40 X 2.30Z & Y
  • 35
    8408-880 SCREW,CAP-HFH M8X1.25X80 CL8.8 Z & Y
    SCREW,CAP-HFH M8X1.25X80 CL8.8 Z & Y
  • 36
    2704-337 BUSHING, ADJUSTER
    BUSHING, ADJUSTER
  • 37
    3604-060 WHEEL, IDLER (INC. 5-6)
    WHEEL, IDLER (INC. 5-6)
  • 38
    1604-940 SPACER,REAR WHEEL- 6.456 LG
    SPACER,REAR WHEEL- 6.456 LG
  • 39
    3604-980 AXLE,STEEL-REAR WHEEL-M8-19.9X343.4
    AXLE,STEEL-REAR WHEEL-M8-19.9X343.4
  • 40
    3604-647 ADJUSTER,TRACK-8MM-CAST
    ADJUSTER,TRACK-8MM-CAST
  • 41
    0623-921 WASHER FLAT.788ID X 1.5OD X .109
    WASHER FLAT.788ID X 1.5OD X .109
  • 42
    8422-802 NUT,HEX-THK NYL M8X1.25 CL8 Z & Y
    NUT,HEX-THK NYL M8X1.25 CL8 Z & Y
  • 43
    1623-682 SCREW,CAP-HH-M8 X 1.25 X 100 Z & Y
    SCREW,CAP-HH-M8 X 1.25 X 100 Z & Y
  • 44
    3604-063 WHEEL, IDLER - (BLACK) (INC. 5-6)
    WHEEL, IDLER - (BLACK) (INC. 5-6)
  • 45
    0623-664 WASHER,FLAT 1.00X.390X.164 Z & Y
    WASHER,FLAT 1.00X.390X.164 Z & Y
  • 46
    8408-831 SCREW,CAP-HFH M8X1.25X30 CL8.8 W/2353
    SCREW,CAP-HFH M8X1.25X30 CL8.8 W/2353
