BATTERY AND TRAY ASSEMBLY для Arctic Cat M 9000 HCR 162 (GREEN) [S2015M9NHCUSG] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    0745-406 BATTERY, SEALED - YTX20 - ASSEMBLY (INC. 2-3)
    BATTERY, SEALED - YTX20 - ASSEMBLY (INC. 2-3)
  • 2
    0645-430 ...DECAL, WARNING
    ...DECAL, WARNING
  • 3
    0445-082 ...HARDWARE KIT,BATTERY-PACK (010 ATV)
    ...HARDWARE KIT,BATTERY-PACK (010 ATV)
  • 4
    0645-647 BRACKET, HOLD-DOWN - BATTERY
    BRACKET, HOLD-DOWN - BATTERY
  • 5
    8468-625 SCREW,MACH-TSPNH M6X1.0X25 CL8.8 (BLACK)
    SCREW,MACH-TSPNH M6X1.0X25 CL8.8 (BLACK)
  • 6
    8427-602 NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & Y
    NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & Y
  • 7
    0445-092 SOLENOID, STARTER RELAY
    SOLENOID, STARTER RELAY
  • 8
    0645-649 CABLE, BATTERY/SOLENOID (INC. 9-10)
    CABLE, BATTERY/SOLENOID (INC. 9-10)
  • 9
    0645-662 ......BOOT, TERMINAL - BATTERY
    ......BOOT, TERMINAL - BATTERY
  • 10
    0645-697 ...BOOT, TERMINAL - BATTERY
    ...BOOT, TERMINAL - BATTERY
  • 11
    0623-038 NUT,HEX M6 Z & Y-SEMS (W/WASHER)
    NUT,HEX M6 Z & Y-SEMS (W/WASHER)
  • 12
    0645-671 CABLE, SOLENOID/STARTER (INC. 13 AND ONE NO. 9)
    CABLE, SOLENOID/STARTER (INC. 13 AND ONE NO. 9)
  • 13
    0645-019 ...BOOT,TERMINAL-BATTERY
    ...BOOT,TERMINAL-BATTERY
  • 14
    1623-451 SCREW, CAP W/WASHER
    SCREW, CAP W/WASHER
  • 15
    0645-670 CABLE, BATTERY/GROUND
    CABLE, BATTERY/GROUND
  • 16
    0123-788 TIE, CABLE - 8 IN.
    TIE, CABLE - 8 IN.
