HOOD AND AIR INTAKE ASSEMBLY для Arctic Cat XF 800 Sno Pro - GREEN - INTERNATIONAL [S2013XFHSPOSG] - 2013 года выпуска

  • №
    Артикул
    Название
  • 1
    3718-628 HOOD W/DECALS - RIGHT - WHITE (INC. 2-3 AND 5-6)
    HOOD W/DECALS - RIGHT - WHITE (INC. 2-3 AND 5-6)
  • 1
    3718-629 HOOD W/DECALS - LEFT - WHITE (INC. 2-6)
    HOOD W/DECALS - LEFT - WHITE (INC. 2-6)
  • 2
    3718-612 ...HOOD W/O DECALS - RIGHT - WHITE (INC. 3)
    ...HOOD W/O DECALS - RIGHT - WHITE (INC. 3)
  • 2
    3718-613 ...HOOD W/O DECALS - LEFT - WHITE (INC. 3-4)
    ...HOOD W/O DECALS - LEFT - WHITE (INC. 3-4)
  • 3
    0617-646 ......FOAM, HOOD - RIGHT
    ......FOAM, HOOD - RIGHT
  • 3
    0617-647 ......FOAM, HOOD - LEFT
    ......FOAM, HOOD - LEFT
  • 4
    6606-407 ......FOIL, PROTECTIVE
    ......FOIL, PROTECTIVE
  • 5
    0621-006 ...DECAL, HOOD - FORWARD RIGHT
    ...DECAL, HOOD - FORWARD RIGHT
  • 5
    0621-007 ...DECAL, HOOD - FORWARD LEFT
    ...DECAL, HOOD - FORWARD LEFT
  • 6
    0621-004 ...DECAL, HOOD - REAR RIGHT
    ...DECAL, HOOD - REAR RIGHT
  • 6
    0621-005 ...DECAL, HOOD - REAR LEFT
    ...DECAL, HOOD - REAR LEFT
  • 7
    0623-784 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 8
    1623-960 O-RING
    O-RING
  • 9
    5706-356 PLENUM, INTAKE - UPPER (INC. 10)
    PLENUM, INTAKE - UPPER (INC. 10)
  • 10
    0617-648 ...FOAM, INTAKE
    ...FOAM, INTAKE
  • 11
    9611-752 DECAL, CREST - GREEN
    DECAL, CREST - GREEN
  • 12
    6606-386 BOOT, INTAKE
    BOOT, INTAKE
  • 13
    0623-165 CLIP, RETAINING
    CLIP, RETAINING
  • 14
    1623-933 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 15
    0623-797 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 16
    1623-939 CLIP, U-NUT
    CLIP, U-NUT
  • 17
    1623-929 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 18
    5706-358 PLENUM, INTAKE - LOWER REAR (INC. 19)
    PLENUM, INTAKE - LOWER REAR (INC. 19)
  • 19
    6606-406 ...FOIL, PROTECTIVE
    ...FOIL, PROTECTIVE
  • 20
    0617-682 FOAM, INTAKE
    FOAM, INTAKE
  • 21
    1623-637 CLIP, U-NUT
    CLIP, U-NUT
  • 22
    5706-357 PLENUM, INTAKE - LOWER FRONT (INC. 23)
    PLENUM, INTAKE - LOWER FRONT (INC. 23)
  • 23
    9611-835 ...DECAL, REFLECTOR - AMBER
    ...DECAL, REFLECTOR - AMBER
  • 24
    0617-624 ADAPTER, BOOT
    ADAPTER, BOOT
  • 25
    2670-328 BOOT
    BOOT
  • 26
    0423-018 CLAMP
    CLAMP
