SKI AND SPINDLE ASSEMBLY для Arctic Cat T570 - 2012 года выпуска`
-
№АртикулНазвание
-
10623-831 CAP, SPINDLECAP, SPINDLE
-
22703-372 SPINDLE, STEERING - RIGHT - BLACK (INC. 3-10)SPINDLE, STEERING - RIGHT - BLACK (INC. 3-10)
-
22703-373 SPINDLE, STEERING - LEFT - BLACK (INC. 3-10)SPINDLE, STEERING - LEFT - BLACK (INC. 3-10)
-
30623-796 ...RING, RETAINING...RING, RETAINING
-
44706-272 ...ARM, SPINDLE - RIGHT - BLACK...ARM, SPINDLE - RIGHT - BLACK
-
44706-273 ...ARM, SPINDLE - LEFT - BLACK...ARM, SPINDLE - LEFT - BLACK
-
50623-872 ...SCREW, CAP...SCREW, CAP
-
62603-382 ...WASHER, THRUST...WASHER, THRUST
-
71623-654 ...FITTING, GREASE...FITTING, GREASE
-
81603-895 ...BEARING...BEARING
-
91623-582 ...SCREW, CAP...SCREW, CAP
-
100603-158 ...BEARING...BEARING
-
112603-813 AXLE, SPINDLEAXLE, SPINDLE
-
120603-036 DAMPER, SKIDAMPER, SKI
-
132603-833 SKI, PLASTIC - BLACKSKI, PLASTIC - BLACK
-
142603-746 INSERTINSERT
-
152603-598 HANDLE, PLASTIC - BLACKHANDLE, PLASTIC - BLACK
-
168047-366 NUT, LOCKNUT, LOCK
-
171623-688 SCREW, MACHINESCREW, MACHINE
-
181623-689 SCREW, MACHINESCREW, MACHINE
-
190703-871 WEARBARWEARBAR
-
208047-486 NUT, LOCKNUT, LOCK
-
210423-744 NUT, LOCKNUT, LOCK
-
221623-801 WASHERWASHER
-
230123-458 PIN, COTTERPIN, COTTER
-
241623-781 SCREW, CAPSCREW, CAP
