HOOD AND WINDSHIELD ASSEMBLY для Arctic Cat T660 TOURING - 2008 года выпуска`
-
№АртикулНазвание
-
12718-068 HOOD W/DECALS - BLACK (INC. 2-22 AND TWELVE NO. 23)HOOD W/DECALS - BLACK (INC. 2-22 AND TWELVE NO. 23)
-
22718-067 ...HOOD W/O DECALS - BLACK (INC. 3-16)...HOOD W/O DECALS - BLACK (INC. 3-16)
-
30717-186 ......FOAM, HOOD - GAUGE - RIGHT......FOAM, HOOD - GAUGE - RIGHT
-
30717-187 ......FOAM, HOOD - GAUGE - LEFT......FOAM, HOOD - GAUGE - LEFT
-
40717-190 ......FOAM, HOOD - UPPER RIGHT......FOAM, HOOD - UPPER RIGHT
-
40717-191 ......FOAM, HOOD - UPPER LEFT......FOAM, HOOD - UPPER LEFT
-
50717-184 ......FOAM, HOOD - FRONT - RIGHT......FOAM, HOOD - FRONT - RIGHT
-
50717-185 ......FOAM, HOOD - FRONT - LEFT......FOAM, HOOD - FRONT - LEFT
-
60717-193 ......FOAM, HOOD - MIDDLE......FOAM, HOOD - MIDDLE
-
73606-359 ......FOIL, HOOD - CENTER......FOIL, HOOD - CENTER
-
85611-840 ......DECAL, WARNING (ENGLISH)......DECAL, WARNING (ENGLISH)
-
85611-841 ......DECAL, WARNING (FRENCH)......DECAL, WARNING (FRENCH)
-
95611-836 ......DECAL, REVERSE......DECAL, REVERSE
-
105611-837 ......DECAL, WARNING - BREAK-IN......DECAL, WARNING - BREAK-IN
-
113606-236 ......SCREEN, HOOD - REAR - RIGHT......SCREEN, HOOD - REAR - RIGHT
-
113606-237 ......SCREEN, HOOD - REAR - LEFT......SCREEN, HOOD - REAR - LEFT
-
124606-161 ......SCREEN, HOOD - MIDDLE......SCREEN, HOOD - MIDDLE
-
133606-234 ......SCREEN, HOOD - FRONT - RIGHT......SCREEN, HOOD - FRONT - RIGHT
-
133606-235 ......SCREEN, HOOD - FRONT - LEFT......SCREEN, HOOD - FRONT - LEFT
-
140123-987 ......CLIP, RETAINING......CLIP, RETAINING
-
153606-934 ......INSERT, SCREEN VENT......INSERT, SCREEN VENT
-
160623-165 ......CLIP, RETAINING......CLIP, RETAINING
-
177611-492 ...DECAL, HOOD - LOWER RIGHT...DECAL, HOOD - LOWER RIGHT
-
177611-493 ...DECAL, HOOD - LOWER LEFT...DECAL, HOOD - LOWER LEFT
-
186611-805 ...EMBLEM, HOOD...EMBLEM, HOOD
-
192718-016 ...COVER, HOOD W/DECALS (INC. 20-21)...COVER, HOOD W/DECALS (INC. 20-21)
-
203606-253 ......COVER, HOOD W/O DECALS......COVER, HOOD W/O DECALS
-
217611-489 ......DECAL, HOOD COVER - CREST......DECAL, HOOD COVER - CREST
-
220619-946 ...TAPE, FOAM - 1 FT...TAPE, FOAM - 1 FT
-
230616-032 ...O-RING...O-RING
-
240717-192 FOAM, HOOD - UPPER MIDDLEFOAM, HOOD - UPPER MIDDLE
-
252639-477 MIRROR - KIT (INC. SIX NO. 26-28)MIRROR - KIT (INC. SIX NO. 26-28)
-
260623-845 ...NUT, EXPANSION...NUT, EXPANSION
-
270623-902 ...SCREW, MACHINE...SCREW, MACHINE
-
280124-054 ...SNAP CAP W/WASHER...SNAP CAP W/WASHER
-
293606-408 WINDSHIELDWINDSHIELD
-
300623-805 CLIP, HAIRPINCLIP, HAIRPIN
-
312606-247 CABLE, HOODCABLE, HOOD
-
321606-067 STRAP, HOLD-DOWNSTRAP, HOLD-DOWN
-
331623-164 SCREW, SHOULDERSCREW, SHOULDER
