SLIDE RAIL AND TRACK ASSEMBLY для Arctic Cat PANTHER 370 (BLACK) - 2007 года выпуска

  • №
    Артикул
    Название
  • 7999-154 COMPLETE SKID FRAME ASSEMBLY
    COMPLETE SKID FRAME ASSEMBLY
  • 1
    2604-712 RAIL, FORMED
    RAIL, FORMED
  • 2
    0604-426 SUPPORT, RAIL
    SUPPORT, RAIL
  • 3
    8047-366 NUT, LOCK
    NUT, LOCK
  • 4
    8050-217 WASHER
    WASHER
  • 5
    2604-842 END CAP, SLIDE RAIL
    END CAP, SLIDE RAIL
  • 6
    8002-043 SCREW, CAP
    SCREW, CAP
  • 7
    0123-859 SCREW, MACHINE
    SCREW, MACHINE
  • 8
    2604-257 WEARSTRIP, SLIDE RAIL - BLACK
    WEARSTRIP, SLIDE RAIL - BLACK
  • 9
    1623-502 SCREW, CAP
    SCREW, CAP
  • 10
    8060-633 RIVET, SOLID
    RIVET, SOLID
  • 11
    0604-967 BRACKET, RETAINING
    BRACKET, RETAINING
  • 12
    0604-918 PAD, SHOCK
    PAD, SHOCK
  • 13
    8047-426 NUT, LOCK
    NUT, LOCK
  • 14
    0704-395 BRACKET, MOUNTING - FRONT ARM
    BRACKET, MOUNTING - FRONT ARM
  • 15
    8020-132 SCREW, CAP
    SCREW, CAP
  • 16
    8020-227 SCREW, CAP
    SCREW, CAP
  • 17
    1604-413 BLOCK, SPRING TENSION
    BLOCK, SPRING TENSION
  • 18
    8047-486 NUT, LOCK
    NUT, LOCK
  • 19
    8041-246 NUT, LOCK
    NUT, LOCK
  • 20
    1604-429 PAD, SHOCK
    PAD, SHOCK
  • 21
    8017-405 SCREW, MACHINE
    SCREW, MACHINE
  • 22
    2604-562 STOP, REAR ARM
    STOP, REAR ARM
  • 23
    1623-427 SCREW, CAP
    SCREW, CAP
  • 24
    8005-676 SCREW, CAP*
    SCREW, CAP*
  • 25
    0623-044 WASHER*
    WASHER*
  • 26
    2604-545 BLOCK, REAR ARM COUPLER (OPTIONAL)
    BLOCK, REAR ARM COUPLER (OPTIONAL)
  • 27
    2604-046 BUSHING, REAR ARM COUPLER BLOCK (OPTIONAL)
    BUSHING, REAR ARM COUPLER BLOCK (OPTIONAL)
  • 28
    8041-486 NUT, LOCK*
    NUT, LOCK*
  • 29
    8002-042 SCREW, CAP
    SCREW, CAP
  • 30
    0704-352 ADJUSTER, TRACK
    ADJUSTER, TRACK
  • 31
    1602-635 TRACK ASSEMBLY (INC. 32)
    TRACK ASSEMBLY (INC. 32)
  • 32
    1602-907 ...CLIP, GUIDE
    ...CLIP, GUIDE
